총 2개의 상품

제품 번호 / 가격	Brand	Accuracy	Applications	Calibration Option	Compliance	Compliance Note	Coverage Area	Display Type	Drift	Enclosure Type	Gas Concentration	Materials	Operating Temperature, Max	Operating Temperature, Min	Output Detail	Output Signal	Relative Humidity	Relay Output	Resolution	Response Time	Sensor Life	Sensor Type	Set Point	Set Point Differential/Hysteresis	Storage Temperature, Max	Storage Temperature, Min	Switch Rating	Switch Type	Temperature Effect	Weight	Zero Setting Adjustable Range	Additional Features 1	수량 / 장바구니
CMS300-FC가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 5 ppm or 5 %	Building and Maintenance, HVAC	Factory Calibration Certificate	CE, UL	Sensor is UL recognized component for ANSI/UL-2034, UL-2075, E340403, CE	7500 sq ft	N/A	<5%/Year in Air	IP64	0 to 300 ppm	Glass-Filled Polycarbonate	122 °F	-4 °F	Jumper selectable 4-20 mA (loop powered) or 2-10 V (max. load 2 kΩ)	Current, Voltage	15 to 90% RH Constant, 0 to 99% RH Intermittent	Factory Set for Direct Acting	1 ppm	<45 s to 90%	5 Years	Electrochemical	Selectable 25, 60, or 150 PPM	3 % scale	68 °F	32 °F	NO: 5 A @ 30 Vdc, 250 Vac; NC: 3 A @ 30 Vdc, 250 Vac	SPDT NO/NC, Selectable	± 2% Over Range	1 lb	15 Turn Potentiometers	Factory Calibration Certificate
CMS300가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 5 ppm or 5 %	Building and Maintenance, HVAC	N/A	CE, UL	Sensor is UL recognized component for ANSI/UL-2034, UL-2075, E340403, CE	7500 sq ft	N/A	<5%/Year in Air	IP64	0 to 300 ppm	Glass-Filled Polycarbonate	122 °F	-4 °F	Jumper selectable 4-20 mA (loop powered) or 2-10 V (max. load 2 kΩ)	Current, Voltage	15 to 90% RH Constant, 0 to 99% RH Intermittent	Factory Set for Direct Acting	1 ppm	<45 s to 90%	5 Years	Electrochemical	Selectable 25, 60, or 150 PPM	3 % scale	68 °F	32 °F	NO: 5 A @ 30 Vdc, 250 Vac; NC: 3 A @ 30 Vdc, 250 Vac	SPDT NO/NC, Selectable	± 2% Over Range	1 lb	15 Turn Potentiometers	-

스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.

제품 번호 / 가격

Brand

Accuracy

Applications

Calibration Option

Compliance

Compliance Note

Coverage Area

Display Type

Drift

Enclosure Type

Gas Concentration

Materials

Operating Temperature, Max

Operating Temperature, Min

Output Detail

Output Signal

Relative Humidity

Relay Output

Resolution

Response Time

Sensor Life

Sensor Type

Set Point

Set Point Differential/Hysteresis

Storage Temperature, Max

Storage Temperature, Min

Switch Rating

Switch Type

Temperature Effect

Weight

Zero Setting Adjustable Range

Additional Features 1

수량 / 장바구니

CMS300-FC가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 5 ppm or 5 %

Building and Maintenance, HVAC

Factory Calibration Certificate

CE, UL

Sensor is UL recognized component for ANSI/UL-2034, UL-2075, E340403, CE

7500 sq ft

N/A

<5%/Year in Air

IP64

0 to 300 ppm

Glass-Filled Polycarbonate

122 °F

-4 °F

Jumper selectable 4-20 mA (loop powered) or 2-10 V (max. load 2 kΩ)

Current, Voltage

15 to 90% RH Constant, 0 to 99% RH Intermittent

Factory Set for Direct Acting

1 ppm

<45 s to 90%

5 Years

Electrochemical

Selectable 25, 60, or 150 PPM

3 % scale

68 °F

32 °F

NO: 5 A @ 30 Vdc, 250 Vac; NC: 3 A @ 30 Vdc, 250 Vac

SPDT NO/NC, Selectable

± 2% Over Range

1 lb

15 Turn Potentiometers
