총 1개의 상품

제품 번호 / 가격	Brand	Accuracy	Accuracy Class	Accuracy Detail	Electrical Connection	Electrical Output	Electrical Output Note	Enclosure Ratings	Fill Fluid	Loop Resistance, Max	Materials, Wetted	Measurement Pressure Type	Measurement Pressure, Max	Measurement Pressure, Min	Operating Temperature, Max	Operating Temperature, Min	Output Signal	Process Connection Size	Process Connection Type	Proof Pressure	Proof Pressure Note	Relative Humidity	Span Setting Adjustable Range	Storage Temperature, Max	Storage Temperature, Min	Supply Voltage	Thermal Effect on Span error, Max	Thermal Effect on Zero error, Max	Vibration	Weight	Zero/Balance Error	수량 / 장바구니
PX831-015GI1,431,960 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	± 0.3 %	> 0.25%	± 0.3% of span @ 25°C (includes linearity, hysteresis and repeatability)	1/2 in NPT male Conduit with Cable	4 to 20 mA	4 to 20 mA(2 wire)	IP66, NEMA Type 4	DC 200 silicone oil	900 Ω @ 30 Vdc	316 Stainless Steel, 316L Stainless Steel	Gauge	15 psi	0 psi	60 °C	-40 °C	Current	1/2 in	NPT Female	3x Full Scale	300% of rated pressure	0 to 1	16 mA ± 1% of span	100 °C	-40 °C	12 to 30 Vdc	± 2%	± 2%, ± 2%	± 0.1% FS for 3 g to 200 Hz	374 g	4 mA ± 2%

스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.

제품 번호 / 가격

Brand

Accuracy

Accuracy Class

Accuracy Detail

Electrical Connection

Electrical Output

Electrical Output Note

Enclosure Ratings

Fill Fluid

Loop Resistance, Max

Materials, Wetted

Measurement Pressure Type

Measurement Pressure, Max

Measurement Pressure, Min

Operating Temperature, Max

Operating Temperature, Min

Output Signal

Process Connection Size

Process Connection Type

Proof Pressure

Proof Pressure Note

Relative Humidity

Span Setting Adjustable Range

Storage Temperature, Max

Storage Temperature, Min

Supply Voltage

Thermal Effect on Span error, Max

Thermal Effect on Zero error, Max

Vibration

Weight

Zero/Balance Error

수량 / 장바구니

PX831-015GI1,431,960 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

± 0.3 %

> 0.25%

± 0.3% of span @ 25°C (includes linearity, hysteresis and repeatability)

1/2 in NPT male Conduit with Cable

4 to 20 mA

4 to 20 mA(2 wire)

IP66, NEMA Type 4

DC 200 silicone oil

900 Ω @ 30 Vdc

316 Stainless Steel, 316L Stainless Steel

Gauge

15 psi

0 psi

60 °C

-40 °C

Current

1/2 in

NPT Female

3x Full Scale

300% of rated pressure

0 to 1

16 mA ± 1% of span

100 °C

-40 °C

12 to 30 Vdc

± 2%

± 2%, ± 2%

± 0.1% FS for 3 g to 200 Hz

374 g

4 mA ± 2%
