총 14개의 상품

제품 번호 / 가격	Brand	Approvals	Burst Pressure	Control Output	Deadband	Deadband Type	Electrical Connection	Enclosure Ratings	Height	Lead Length	Length	Materials	Materials, Wetted	Measurement Pressure Type	Measurement Pressure, Max	Measurement Pressure, Min	Output Note	Output Value	Process Connection Size	Process Connection Type	Process Temperature, Max	Process Temperature, Min	Proof Pressure	Repeatability	Repeatability Note	Supply Power Note	Supply Voltage	Switch	Switch Type	Width	Wire Gauge	수량 / 장바구니
PSW601B-7.5K1,371,440 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	11,250 psi Maximum	SPDT Relay	382.1 to 7143.8 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	7500 psi	375 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	NPT Female	71 °C	-29 °C	Up to 9000 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
PSW601B-7501,371,440 원14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	6000 psi Maximum	SPDT Relay	35.7 to 714.3 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	750 psi	35 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	NPT Female	71 °C	-29 °C	Up to 1500 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
PSW601B-3001,539,380 원14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	2400 psi Maximum	SPDT Relay	15.3 to 285.8 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	300 psi	15 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	NPT Female	71 °C	-29 °C	Up to 600 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
PSW601B-5001,371,440 원14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	4000 psi Maximum	SPDT Relay	25.5 to 476.3 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	500 psi	25 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	NPT Female	71 °C	-29 °C	Up to 1000 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
PSW601B-2001,539,380 원14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	1600 psi Maximum	SPDT Relay	10.2 to 190.5 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	200 psi	10 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	NPT Female	71 °C	-29 °C	Up to 400 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
PSW601B-1001,539,380 원14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	800 psi Maximum	SPDT Relay	5.1 to 95.3 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	100 psi	5 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	NPT Female	71 °C	-29 °C	Up to 200 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
PSW601A-15K1,539,380 원14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	22,000 psi Maximum	SPDT Relay	764.3 to 14287.5 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	15000 psi	750 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	UNF Female	71 °C	-29 °C	Up to 18000 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
PSW601A-20K1,539,380 원14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	30,000 psi Maximum	SPDT Relay	1019 to 19050 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	20000 psi	1000 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	UNF Female	71 °C	-29 °C	Up to 24000 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
PSW601A-10K1,539,380 원14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	15,000 psi Maximum	SPDT Relay	509.5 to 9525 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	10000 psi	500 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	UNF Female	71 °C	-29 °C	Up to 12000 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
PSW601B-601,385,440 원14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	480 psi Maximum	SPDT Relay	3.1 to 57.2 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	60 psi	3 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	NPT Female	71 °C	-29 °C	Up to 120 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
PSW601B-5K1,379,040 원14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	15,000 psi Maximum	SPDT Relay	254.8 to 4762.5 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	5000 psi	250 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	NPT Female	71 °C	-29 °C	Up to 7500 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
PSW601B-3K1,539,380 원14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	9000 psi Maximum	SPDT Relay	152.9 to 2857.5 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	3000 psi	150 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	NPT Female	71 °C	-29 °C	Up to 4000 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
PSW601B-1K1,539,380 원17 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	8000 psi Maximum	SPDT Relay	50.9 to 952.5 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	1000 psi	50 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	NPT Female	71 °C	-29 °C	Up to 2000 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
PSW601B-2K1,539,380 원14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL listed	16,000 psi Maximum	SPDT Relay	101.9 to 1905 psi	Adjustable	1/2 in NPT female Conduit with Wire Leads	IP65, NEMA Type 4X	5.7 in	18 in	2.3 in	Aluminum	17-4 Stainless Steel, 316 Stainless Steel	Gauge	2000 psi	100 psi	10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive	10A @ 125/250 Vac	1/4 in	NPT Female	71 °C	-29 °C	Up to 4000 psi	± 0.5%	± 0.5% full range	Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz	24 Vdc	Single	SPDT NO/NC, Selectable	4 in	18 AWG
