DwyerOmegaPSW-601
PSW601B-100
5 to 100 psi, adjustable deadband
- 가격
- 1,539,380 원
- VAT 10%
- 153,938 원
- 총 금액
- 1,693,318 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 14 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Approvals:UL listed
Burst Pressure:800 psi Maximum
Control Output:SPDT Relay
Deadband:5.1 to 95.3 psi
Deadband Type:Adjustable
Electrical Connection:1/2 in NPT female Conduit with Wire Leads
Enclosure Ratings:IP65, NEMA Type 4X
Height:5.7 in
Lead Length:18 in
Length:2.3 in
Materials:Aluminum
Materials, Wetted:17-4 Stainless Steel, 316 Stainless Steel
Measurement Pressure Type:Gauge
Measurement Pressure, Max:100 psi
Measurement Pressure, Min:5 psi
Output Note:10 A 125/250 Vac resistive and inductive; 10 A, 30 Vdc resistive
Output Value:10A @ 125/250 Vac
Process Connection Size:1/4 in
Process Connection Type:NPT Female
Process Temperature, Max:71 °C
Process Temperature, Min:-29 °C
Proof Pressure:Up to 200 psi
Repeatability:± 0.5%
Repeatability Note:± 0.5% full range
Supply Power Note:Standard: 24 Vdc, 12 mA unactivated; 43 mA activated Optional: 110 to 120 Vac 50/60 Hz or 250 Vac 50/60 Hz
Supply Voltage:24 Vdc
Switch:Single
Switch Type:SPDT NO/NC, Selectable
Width:4 in
Wire Gauge:18 AWG
