제품 번호 / 가격	Brand	Accuracy	Applications	Compliance	Current Output	Input Note	Measurement Type	Number of Wires	Operating Temperature, Max	Operating Temperature, Min	Output Detail	Output Signal	Response Time	Response Time Note	Sensor Type	Supply Power Type	Supply Voltage	Temperature Drift	Temperature Input Range	Voltage Accuracy	Voltage Input Range	Weight	수량 / 장바구니
TBU-00가격 문의18 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 0.1 %	Boilers, Oil, Refrigeration, Refrigeration Equipment	CE	4 to 20 mA	Thermocouples J, K, R, S, T, N, E, and B; 2, 3, or 4-wire Pt100 RTD, 2 or 3-wire Pt1000 RTD, 2-wire NTC thermistor, or 0-50 mV voltage. RTD: 238 to 752°F, Thermocouple: 32 to 1202 °F	Thermocouple, RTD, Thermistor, Voltage	2, 3, 4	185 °F	-40 °F	Linearized 4-20 mA, 2-wire or 20-4 mA loop powered	Current	1.6 s	1.6 s, typical.	Thermocouple, RTD, Thermistor	DC	10 to 35 Vdc	<± 0.16%/25°C	32 to 1202 °F	± 0.13%	0 to 50 mV	40 g

스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.

제품 번호 / 가격

Brand

Accuracy

Applications

Compliance

Current Output

Input Note

Measurement Type

Number of Wires

Operating Temperature, Max

Operating Temperature, Min

Output Detail

Output Signal

Response Time

Response Time Note

Sensor Type

Supply Power Type

Supply Voltage

Temperature Drift

Temperature Input Range

Voltage Accuracy

Voltage Input Range

Weight

수량 / 장바구니

TBU-00가격 문의18 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 0.1 %

Boilers, Oil, Refrigeration, Refrigeration Equipment

4 to 20 mA

Thermocouples J, K, R, S, T, N, E, and B; 2, 3, or 4-wire Pt100 RTD, 2 or 3-wire Pt1000 RTD, 2-wire NTC thermistor, or 0-50 mV voltage. RTD: 238 to 752°F, Thermocouple: 32 to 1202 °F

Thermocouple, RTD, Thermistor, Voltage

2, 3, 4

185 °F

-40 °F

Linearized 4-20 mA, 2-wire or 20-4 mA loop powered

Current

1.6 s

1.6 s, typical.

Thermocouple, RTD, Thermistor

10 to 35 Vdc

<± 0.16%/25°C

32 to 1202 °F

± 0.13%

0 to 50 mV

40 g
