DwyerOmegaPR-14
PR-14E-3-100-1/4-24
RTD Probe with Miniature Aluminum Protection Head
- 가격
- 328,800 원
- VAT 10%
- 32,880 원
- 총 금액
- 361,680 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 5 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Accuracy:Class A
Accuracy Detail:Class A from -100 to 450°C (-148 to 842°F); or else Class B
Enclosure Ratings:IP67
Head Material:Aluminum
Nominal Resistance:100 Ω
Nominal Resistance Note:100 Ω and 1000 Ω at 0°C standard; TCR = 0.00385 Ω/Ω/°C standard
Number of Wires:3
Probe Diameter:0.25 in
Probe Length:24 in
Process Connection Size:1/2 in
Process Connection Type:NPT Male
Process Temperature, Max:600 °C
Process Temperature, Min:-200 °C
Protection Head:NB2 Die-Cast Aluminum, Safety Chain, Medium
Response Time:10.6 sec
Sheath Material:316 Stainless Steel
Shock:IEC 60068-2-27; 50g/11ms (15 probes tested together) Duration: 1 day
Temperature Coefficient:0.00385 Ω/Ω/°C standard
Temperature Probe Style:N/A
Temperature Sensor Type:RTD
Vibration:IEC 60068-2-6; 5 to 2000 Hz sweep rate, one active per minute; number of sweep cycles 10 and acceleration 5g (15 probes tested together) Duration: 1 day
