DwyerOmegaOB-OMEGABOND-AIR-SET
OB-300
High Temperature Cements
- 가격
- 105,320 원
- VAT 10%
- 10,532 원
- 총 금액
- 115,852 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 2 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Applications:Bonding, Insulating, Sealing
Color:Off white
Dielectric Constant:3.5 to 6.0
Dielectric Strength Note:Dielectric Strength at 20°C:12.5 to 51.0 V/mil;Dielectric Strength at 400°C: ≤15 V/mil;Dielectric Strength at 795°C: ≤1.3 V/mil
Features:Lower thermal conductivity and coefficient of thermal expansion
Insulation Note:Volume Resistivity at 20°C: 10⁸-10⁹ ohm–cm;Volume Resistivity at 400°C: 10⁴-10⁵ ohm–cm;Volume Resistivity at 795°C: 10²-10³ ohm–cm
Material Construction Option:Low Expansion Cement
Mechanical Strength Properties:Tensile Shear Strength: 410 psi; Compressive Strength: 3900 psi; Shear Strength: 710 psi
Mix Ratio By Weight:1-part cement; just mix powder with water to a smooth, uniform consistency
Modulus of Rupture:460 psi
Operating Temperature, Max:980 °C
Thermal Conductivity:4 to 6 BTU-in/h-ft2-°F
Thermal Expansion Coefficient:6.2 x 10^-6 in/in/°F
Volume:8 oz
Working Life:OMEGABOND 300® cures at room temperature by air drying in 18 to 24-hr, depending upon thickness and consistency; cure time can be accelerated by low temperature oven drying at 82°C (180°F); if the cement is to be exposed to elevated temperatures, cure for 18 to 24-hr at ambient temperature, then oven dry for 4-hr at 82°C (180°F) and for an additional 4-hr at 105°C (220°F), this helps to prevent spilling.
