DwyerOmegaAlta-Gas
MNS2-9-W2-GS-C1
ALTA Wireless Carbon Monoxide (CO) Gas Sensor- AA Battery Powered 900 MHz
- 판매 가격
- 가격 문의
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 11 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Approvals:CE, FCC
Approvals Note:FCC ID: ZTL- G2SC1 and IC: 9794A-G2SC1
Data Interface:Wireless
Display Type:N/A
Electrical Connection:N/A
Enclosure Material:N/A
Form factor:Wall Mount
Height:2.47 in
Input Range:0 to 1000 ppm
Input Type:N/A
Length:1.111 in
Media Compatibility:Air, Gases, Nitrogen, Oxygen
Number of Channels:1
Operating Temperature Note:-30°C to 55°C (-20°F to 130°F) using alkaline, -40°C to 85°C (-40°F to 185°F) using lithium
Operating Temperature, Max:55 °C
Operating Temperature, Min:-30 °C
Power Consumption:35 mA
Power Consumption Note:Sleep Mode:0.7 µA, Radio idle/off Mode: 2 mA, Measurement Mode: 2 mA, Radio RX Mode: 25 mA, Radio TX Mode: 35 mA
Probe Diameter:0 in
Probe Length:0 in
Relative Humidity:15 to 95% RH
Resolution:Gas: ± 1 PPM
Response Time:< 40 sec
Sensor Note:Measuring Principle: Electrochemical Oxidation of CO
Sensor Type:Carbon Monoxide Gas (CO)
Sheath Material:N/A
Span Temperature Drift:Output Signal ≤ ± 2% of reading per month
Stabilization Time:< 120 sec
Supply Power Note:DC: 2.0 - 3.8 VDC (3.0 - 3.8 VDC using power supply), Solar panel: 5VDC/30mA (53mm x 30mm), Charging temperature range: 0°C to 45°C (32°F to 113°F), Max temperature range: -20°C to 60°C (-4°F to 140°F), Included rechargeable battery: 600 mAh/>2000 charge cycles (80% of initial capacity), Solar efficiency: Optimized for high and low-light operation
Supply Power Type:DC/Battery
Supply Voltage:2.0 to 3.8 Vdc
Temperature Probe Style:N/A
Thermal Effect Zero Shift:< 8 ppm equivalent (-20°C to +40°C)
Weight:4 oz
Width:4.375 in
Wire Length:0 ft
Wireless Range:1200 ft
Zero Temperature Drift:Zero Signal ≤ ± 2 PPM / month
