Model-641B | Britestone

모델 보기

필터 또는 검색 기능을 사용하여 원하시는 모델을 찾으십시오.

총 2개의 상품

제품 번호 / 가격	Brand	Accuracy	Accuracy Detail	Air Velocity, Max	Air Velocity, Min	Display Type	Electrical Connection	Electrical Output	Enclosure Ratings	Filter	Loop Resistance	Media Compatibility	Mounting Orientation	Number of Wires	Operating Temperature, Max	Operating Temperature, Min	Output Detail	Power Consumption	Probe Length	Process Temperature, Max	Process Temperature, Min	Relative Humidity	Response Time	Response Time Note	Supply Power Note	Supply Power Type	Supply Voltage	Weight	수량 / 장바구니
641B-4-LED가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 5 %	5% FS process gas: 32 to 122°F (0 to 50°C); 6% FS process gas: -40 to 32°F and 122 to 176°F (-40 to 0°C and 50 to 80°C)	2000 FPM	250 FPM	LED	Screw Terminal	4 to 20 mA	-	0.5 to 15 s (Selectable)	600 Ω max	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases	None	4	140 °F	32 °F	4 to 20 mA, isolated 24 V source, 3 or 4-wire connection	300 mA	4 in	176 °F	-40 °F	Non-Condensing	1.5 s to 95%	Flow: 1.5 s to 95% of final value (output filter set to minimum)	12 to 35 Vdc, 10 to16 Vac. 1.5 A rating required on supply due to initial power surge drawn by transmitter	AC/DC	10 to 16 Vac, 12 to 35 Vdc	12.6 oz
641B-4가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 5 %	5% FS process gas: 32 to 122°F (0 to 50°C); 6% FS process gas: -40 to 32°F and 122 to 176°F (-40 to 0°C and 50 to 80°C)	2000 FPM	250 FPM	N/A	Screw Terminal	4 to 20 mA	IP66, NEMA Type 4X	0.5 to 15 s (Selectable)	600 Ω max	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases	None	4	140 °F	32 °F	4 to 20 mA, isolated 24 V source, 3 or 4-wire connection	300 mA	4 in	176 °F	-40 °F	Non-Condensing	1.5 s to 95%	Flow: 1.5 s to 95% of final value (output filter set to minimum)	12 to 35 Vdc, 10 to16 Vac. 1.5 A rating required on supply due to initial power surge drawn by transmitter	AC/DC	10 to 16 Vac, 12 to 35 Vdc	12.6 oz

스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.

제품 번호 / 가격

Brand

Accuracy

Accuracy Detail

Air Velocity, Max

Air Velocity, Min

Display Type

Electrical Connection

Electrical Output

Enclosure Ratings

Filter

Loop Resistance

Media Compatibility

Mounting Orientation

Number of Wires

Operating Temperature, Max

Operating Temperature, Min

Output Detail

Power Consumption

Probe Length

Process Temperature, Max

Process Temperature, Min

Relative Humidity

Response Time

Response Time Note

Supply Power Note

Supply Power Type

Supply Voltage

Weight

수량 / 장바구니

641B-4-LED가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 5 %

5% FS process gas: 32 to 122°F (0 to 50°C); 6% FS process gas: -40 to 32°F and 122 to 176°F (-40 to 0°C and 50 to 80°C)

2000 FPM

250 FPM

LED

Screw Terminal

4 to 20 mA

0.5 to 15 s (Selectable)

600 Ω max

Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases

None

140 °F

32 °F

4 to 20 mA, isolated 24 V source, 3 or 4-wire connection

300 mA

4 in

176 °F

-40 °F

Non-Condensing

1.5 s to 95%

Flow: 1.5 s to 95% of final value (output filter set to minimum)

12 to 35 Vdc, 10 to16 Vac. 1.5 A rating required on supply due to initial power surge drawn by transmitter

AC/DC

10 to 16 Vac, 12 to 35 Vdc

12.6 oz

641B-4가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다.
