EXPP-K-UL | Britestone

모델 보기

필터 또는 검색 기능을 사용하여 원하시는 모델을 찾으십시오.

총 136개의 상품 · 1 - 20 표시

제품 번호 / 가격	Brand	Additional Features 1	Alloy Material (+)	Alloy Material (-)	Cable Length	Cable Type	Color Code Standard	Conductor Insulation Size	Insulation	Nominal Conductor Size	Nominal Size	Overall Insulation Size	Process Temperature, Max	Special Limits of Error	Thermocouple Type	Use With Sensor Type	Weight	Weight Note	Wire Gauge	Wire Type	Wiring/Connector Table
EXPP-TI-20-UL-100M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Copper	Constantan	100 m	Insulated Thermocouple Extension	IEC	0.38 mm	PVC	0.813 mm	3.5 x 5.2 mm	0.89 mm	105 °C	N/A	T	Thermocouple	10 kg	Wt.kg/300 m†	20 AWG	Solid	Positive Wire - Brown, Negative Wire - White, Overall - Brown
EXPP-T-20S-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Copper	Constantan	1000 ft	Insulated Thermocouple Extension	ANSI	0.015 in	PVC	0.038 in	0.148 x 0.226 in	0.035 in	105 °C	N/A	T	Thermocouple	24 lb	lb/1000 ft	20 AWG	Stranded	Positive Wire - Blue, Negative Wire - Red, Overall - Blue
EXPP-RS-16-UL-7.5M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Copper	Copper	7.5 m	Insulated Thermocouple Extension	ANSI	0.38 mm	PVC	1.3 mm	4.1 x 6.4 mm	0.89 mm	105 °C	N/A	R,S	Thermocouple	16.8 kg	Wt.kg/300 m†	16 AWG	Solid	Positive Wire - Black, Negative Wire - Red, Overall - Green
EXPP-RS-16-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Copper	Copper	1000 ft	Insulated Thermocouple Extension	ANSI	0.015 in	PVC	0.051 in	0.160 x 0.250 in	0.035 in	105 °C	N/A	R,S	Thermocouple	37 lb	lb/1000 ft	16 AWG	Solid	Positive Wire - Black, Negative Wire - Red, Overall - Green
EXPP-RS-16-UL-150M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Copper	Copper	150 m	Insulated Thermocouple Extension	ANSI	0.38 mm	PVC	1.3 mm	4.1 x 6.4 mm	0.89 mm	105 °C	N/A	R,S	Thermocouple	16.8 kg	Wt.kg/300 m†	16 AWG	Solid	Positive Wire - Black, Negative Wire - Red, Overall - Green
EXPP-KI-20S-UL-60M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Chromel	Alumel	60 m	Insulated Thermocouple Extension	IEC	0.38 mm	PVC	0.965 mm	3.8 x 5.7 mm	0.89 mm	105 °C	N/A	K	Thermocouple	10.9 kg	Wt.kg/300 m†	20 AWG	Stranded	Positive Wire - Green, Negative Wire - White, Overall - Green
EXPP-K-20S-UL-300M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Chromel	Alumel	300 m	Insulated Thermocouple Extension	ANSI	0.38 mm	PVC	0.965 mm	3.8 x 5.7 mm	0.89 mm	105 °C	N/A	K	Thermocouple	10.9 kg	Wt.kg/300 m†	20 AWG	Stranded	Positive Wire - Yellow, Negative Wire - Red, Overall - Yellow
EXPP-K-20S-UL-10001,952,510 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Chromel	Alumel	1000 ft	Insulated Thermocouple Extension	ANSI	0.015 in	PVC	0.038 in	0.148 x 0.226 in	0.035 in	105 °C	N/A	K	Thermocouple	24 lb	lb/1000 ft	20 AWG	Stranded	Positive Wire - Yellow, Negative Wire - Red, Overall - Yellow
EXPP-K-20S-UL-150M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Chromel	Alumel	150 m	Insulated Thermocouple Extension	ANSI	0.38 mm	PVC	0.965 mm	3.8 x 5.7 mm	0.89 mm	105 °C	N/A	K	Thermocouple	10.9 kg	Wt.kg/300 m†	20 AWG	Stranded	Positive Wire - Yellow, Negative Wire - Red, Overall - Yellow
EXPP-K-18S-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Chromel	Alumel	1000 ft	Insulated Thermocouple Extension	ANSI	0.015 in	PVC	0.048 in	0.158 x 0.236 in	0.035 in	105 °C	N/A	K	Thermocouple	31 lb	lb/1000 ft	18 AWG	Stranded	Positive Wire - Yellow, Negative Wire - Red, Overall - Yellow
EXPP-K-16S-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Chromel	Alumel	1000 ft	Insulated Thermocouple Extension	ANSI	0.015 in	PVC	0.06 in	0.171 x 0.261 in	0.035 in	105 °C	N/A	K	Thermocouple	39 lb	lb/1000 ft	16 AWG	Stranded	Positive Wire - Yellow, Negative Wire - Red, Overall - Yellow
EXPP-JI-20-UL-100M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Iron	Constantan	100 m	Insulated Thermocouple Extension	IEC	0.38 mm	PVC	0.81 mm	3.5 x 5.2 mm	0.89 mm	105 °C	N/A	J	Thermocouple	10 kg	Wt.kg/300 m†	20 AWG	Solid	Positive Wire - White, Negative Wire - Red, Overall - Black
EXPP-J-20S-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Iron	Constantan	1000 ft	Insulated Thermocouple Extension	ANSI	0.015 in	PVC	0.038 in	0.148 x 0.226 in	0.035 in	105 °C	N/A	J	Thermocouple	24 lb	lb/1000 ft	20 AWG	Stranded	Positive Wire - White, Negative Wire - Red, Overall - Black
EXPP-J-20S-UL-300M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Iron	Constantan	300 m	Insulated Thermocouple Extension	ANSI	0.38 mm	PVC	0.97 mm	3.8 x 5.7 mm	0.89 mm	105 °C	N/A	J	Thermocouple	10.9 kg	Wt.kg/300 m†	20 AWG	Stranded	Positive Wire - White, Negative Wire - Red, Overall - Black
EXPP-J-16S-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Iron	Constantan	1000 ft	Insulated Thermocouple Extension	ANSI	0.015 in	PVC	0.06 in	0.171 x 0.261 in	0.035 in	105 °C	N/A	J	Thermocouple	39 lb	lb/1000 ft	16 AWG	Stranded	Positive Wire - White, Negative Wire - Red, Overall - Black
EXPP-E-18S-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Chromel	Constantan	1000 ft	Insulated Thermocouple Extension	ANSI	0.015 in	PVC	0.048 in	0.158 x 0.236 in	0.035 in	105 °C	N/A	E	Thermocouple	31 lb	lb/1000 ft	18 AWG	Stranded	Positive Wire - Purple, Negative Wire - Red, Overall - Purple
EXPP-T-20S-UL-500가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Copper	Constantan	500 ft	Insulated Thermocouple Extension	ANSI	0.015 in	PVC	0.038 in	0.148 x 0.226 in	0.035 in	105 °C	N/A	T	Thermocouple	24 lb	lb/1000 ft	20 AWG	Stranded	Positive Wire - Blue, Negative Wire - Red, Overall - Blue
EXPP-T-20S-UL-100가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Copper	Constantan	100 ft	Insulated Thermocouple Extension	ANSI	0.015 in	PVC	0.038 in	0.148 x 0.226 in	0.035 in	105 °C	N/A	T	Thermocouple	24 lb	lb/1000 ft	20 AWG	Stranded	Positive Wire - Blue, Negative Wire - Red, Overall - Blue
EXPP-T-20S-UL-200가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Copper	Constantan	200 ft	Insulated Thermocouple Extension	ANSI	0.015 in	PVC	0.038 in	0.148 x 0.226 in	0.035 in	105 °C	N/A	T	Thermocouple	24 lb	lb/1000 ft	20 AWG	Stranded	Positive Wire - Blue, Negative Wire - Red, Overall - Blue
EXPP-T-20-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	UL	Copper	Constantan	1000 ft	Insulated Thermocouple Extension	ANSI	0.015 in	PVC	0.032 in	0.137 x 0.204 in	0.035 in	105 °C	N/A	T	Thermocouple	22 lb	lb/1000 ft	20 AWG	Solid	Positive Wire - Blue, Negative Wire - Red, Overall - Blue

스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.

제품 번호 / 가격

Brand

Additional Features 1

Alloy Material (+)

Alloy Material (-)

Cable Length

Cable Type

Color Code Standard

Conductor Insulation Size

Insulation

Nominal Conductor Size

Nominal Size

Overall Insulation Size

Process Temperature, Max

Process Temperature, Min

Special Limits of Error

Thermocouple Type

Use With Sensor Type

Weight

Weight Note

Wire Gauge

Wire Type

Wiring/Connector Table

수량 / 장바구니

EXPP-TI-20-UL-100M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Copper

Constantan

100 m

Insulated Thermocouple Extension

IEC

0.38 mm

PVC

0.813 mm

3.5 x 5.2 mm

0.89 mm

105 °C

0 °C

N/A

Thermocouple

10 kg

Wt.kg/300 m†

20 AWG

Solid

Positive Wire - Brown, Negative Wire - White, Overall - Brown

EXPP-T-20S-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Copper

Constantan

1000 ft

Insulated Thermocouple Extension

ANSI

0.015 in

PVC

0.038 in

0.148 x 0.226 in

0.035 in

105 °C

0 °C

N/A

Thermocouple

24 lb

lb/1000 ft

20 AWG

Stranded

Positive Wire - Blue, Negative Wire - Red, Overall - Blue

EXPP-RS-16-UL-7.5M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Copper

7.5 m

Insulated Thermocouple Extension

ANSI

0.38 mm

PVC

1.3 mm

4.1 x 6.4 mm

0.89 mm

105 °C

0 °C

N/A

R,S

Thermocouple

16.8 kg

Wt.kg/300 m†

16 AWG

Solid

Positive Wire - Black, Negative Wire - Red, Overall - Green

EXPP-RS-16-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Copper

1000 ft

Insulated Thermocouple Extension

ANSI

0.015 in

PVC

0.051 in

0.160 x 0.250 in

0.035 in

105 °C

0 °C

N/A

R,S

Thermocouple

37 lb

lb/1000 ft

16 AWG

Solid

Positive Wire - Black, Negative Wire - Red, Overall - Green

EXPP-RS-16-UL-150M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Copper

150 m

Insulated Thermocouple Extension

ANSI

0.38 mm

PVC

1.3 mm

4.1 x 6.4 mm

0.89 mm

105 °C

0 °C

N/A

R,S

Thermocouple

16.8 kg

Wt.kg/300 m†

16 AWG

Solid

Positive Wire - Black, Negative Wire - Red, Overall - Green

EXPP-KI-20S-UL-60M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Chromel

Alumel

60 m

Insulated Thermocouple Extension

IEC

0.38 mm

PVC

0.965 mm

3.8 x 5.7 mm

0.89 mm

105 °C

0 °C

N/A

Thermocouple

10.9 kg

Wt.kg/300 m†

20 AWG

Stranded

Positive Wire - Green, Negative Wire - White, Overall - Green

EXPP-K-20S-UL-300M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Chromel

Alumel

300 m

Insulated Thermocouple Extension

ANSI

0.38 mm

PVC

0.965 mm

3.8 x 5.7 mm

0.89 mm

105 °C

0 °C

N/A

Thermocouple

10.9 kg

Wt.kg/300 m†

20 AWG

Stranded

Positive Wire - Yellow, Negative Wire - Red, Overall - Yellow

EXPP-K-20S-UL-10001,952,510 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Chromel

Alumel

1000 ft

Insulated Thermocouple Extension

ANSI

0.015 in

PVC

0.038 in

0.148 x 0.226 in

0.035 in

105 °C

0 °C

N/A

Thermocouple

24 lb

lb/1000 ft

20 AWG

Stranded

Positive Wire - Yellow, Negative Wire - Red, Overall - Yellow

EXPP-K-20S-UL-150M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Chromel

Alumel

150 m

Insulated Thermocouple Extension

ANSI

0.38 mm

PVC

0.965 mm

3.8 x 5.7 mm

0.89 mm

105 °C

0 °C

N/A

Thermocouple

10.9 kg

Wt.kg/300 m†

20 AWG

Stranded

Positive Wire - Yellow, Negative Wire - Red, Overall - Yellow

EXPP-K-18S-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Chromel

Alumel

1000 ft

Insulated Thermocouple Extension

ANSI

0.015 in

PVC

0.048 in

0.158 x 0.236 in

0.035 in

105 °C

0 °C

N/A

Thermocouple

31 lb

lb/1000 ft

18 AWG

Stranded

Positive Wire - Yellow, Negative Wire - Red, Overall - Yellow

EXPP-K-16S-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Chromel

Alumel

1000 ft

Insulated Thermocouple Extension

ANSI

0.015 in

PVC

0.06 in

0.171 x 0.261 in

0.035 in

105 °C

0 °C

N/A

Thermocouple

39 lb

lb/1000 ft

16 AWG

Stranded

Positive Wire - Yellow, Negative Wire - Red, Overall - Yellow

EXPP-JI-20-UL-100M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Iron

Constantan

100 m

Insulated Thermocouple Extension

IEC

0.38 mm

PVC

0.81 mm

3.5 x 5.2 mm

0.89 mm

105 °C

0 °C

N/A

Thermocouple

10 kg

Wt.kg/300 m†

20 AWG

Solid

Positive Wire - White, Negative Wire - Red, Overall - Black

EXPP-J-20S-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Iron

Constantan

1000 ft

Insulated Thermocouple Extension

ANSI

0.015 in

PVC

0.038 in

0.148 x 0.226 in

0.035 in

105 °C

0 °C

N/A

Thermocouple

24 lb

lb/1000 ft

20 AWG

Stranded

Positive Wire - White, Negative Wire - Red, Overall - Black

EXPP-J-20S-UL-300M가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Iron

Constantan

300 m

Insulated Thermocouple Extension

ANSI

0.38 mm

PVC

0.97 mm

3.8 x 5.7 mm

0.89 mm

105 °C

0 °C

N/A

Thermocouple

10.9 kg

Wt.kg/300 m†

20 AWG

Stranded

Positive Wire - White, Negative Wire - Red, Overall - Black

EXPP-J-16S-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Iron

Constantan

1000 ft

Insulated Thermocouple Extension

ANSI

0.015 in

PVC

0.06 in

0.171 x 0.261 in

0.035 in

105 °C

0 °C

N/A

Thermocouple

39 lb

lb/1000 ft

16 AWG

Stranded

Positive Wire - White, Negative Wire - Red, Overall - Black

EXPP-E-18S-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Chromel

Constantan

1000 ft

Insulated Thermocouple Extension

ANSI

0.015 in

PVC

0.048 in

0.158 x 0.236 in

0.035 in

105 °C

0 °C

N/A

Thermocouple

31 lb

lb/1000 ft

18 AWG

Stranded

Positive Wire - Purple, Negative Wire - Red, Overall - Purple

EXPP-T-20S-UL-500가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Copper

Constantan

500 ft

Insulated Thermocouple Extension

ANSI

0.015 in

PVC

0.038 in

0.148 x 0.226 in

0.035 in

105 °C

0 °C

N/A

Thermocouple

24 lb

lb/1000 ft

20 AWG

Stranded

Positive Wire - Blue, Negative Wire - Red, Overall - Blue

EXPP-T-20S-UL-100가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Copper

Constantan

100 ft

Insulated Thermocouple Extension

ANSI

0.015 in

PVC

0.038 in

0.148 x 0.226 in

0.035 in

105 °C

0 °C

N/A

Thermocouple

24 lb

lb/1000 ft

20 AWG

Stranded

Positive Wire - Blue, Negative Wire - Red, Overall - Blue

EXPP-T-20S-UL-200가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Copper

Constantan

200 ft

Insulated Thermocouple Extension

ANSI

0.015 in

PVC

0.038 in

0.148 x 0.226 in

0.035 in

105 °C

0 °C

N/A

Thermocouple

24 lb

lb/1000 ft

20 AWG

Stranded

Positive Wire - Blue, Negative Wire - Red, Overall - Blue

EXPP-T-20-UL-1000가격 문의14 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

Copper

Constantan

1000 ft

Insulated Thermocouple Extension

ANSI

0.015 in

PVC

0.032 in

0.137 x 0.204 in

0.035 in

105 °C

0 °C

N/A

Thermocouple

22 lb

lb/1000 ft

20 AWG

Solid

Positive Wire - Blue, Negative Wire - Red, Overall - Blue
