OEM 스타일, 소형 압력 트랜스미터
필터 또는 검색 기능을 사용하여 원하시는 모델을 찾으십시오.
총 132개의 상품 · 1 - 20 표시
| 제품 번호 / 가격 | Brand | Accuracy | Accuracy Detail | Compensated Temperature, Max | Compensated Temperature, Min | Electrical Connection | Electrical Output | Enclosure Material | Enclosure Ratings | Materials, Wetted | Measurement Pressure Type | Measurement Pressure, Max | Measurement Pressure, Min | Operating Temperature, Max | Operating Temperature, Min | Output Signal | Output Wiring (Pin 1) | Output Wiring (Pin 2) | Process Connection Size | Process Connection Type | Protection | Response Time | Stability | Supply Voltage | Thermal Effect on Span error, Max | Thermal Effect on Zero error, Max | Vibration | Weight | Accuracy Class | 수량 / 장바구니 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PX159A-500G5V295,880 원10 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | M12 4 pin Female | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Gauge | 500 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.011% FS/°F | 0.011% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX159A-200G5V295,880 원10 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | M12 4 pin Female | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Gauge | 200 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.009% FS/°F | 0.009% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX159A-300G5V295,880 원10 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | M12 4 pin Female | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Gauge | 300 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.009% FS/°F | 0.009% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX159A-100G5V295,880 원10 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | M12 4 pin Female | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Gauge | 100 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX159A-100A5V295,880 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | M12 4 pin Female | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Absolute | 100 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX159A-060G5V가격 문의12 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | M12 4 pin Female | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Gauge | 60 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX159A-030G5V295,880 원10 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | M12 4 pin Female | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Gauge | 30 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 10 g (20 to 2000 Hz) | 70 g | - | |
PX159A-060A5V가격 문의12 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | M12 4 pin Female | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Absolute | 60 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX159A-030A5V295,880 원10 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | M12 4 pin Female | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Absolute | 30 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 10 g (20 to 2000 Hz) | 70 g | - | |
PX159A-015G5V295,880 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | M12 4 pin Female | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Gauge | 15 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 10 g (20 to 2000 Hz) | 70 g | - | |
PX159A-015A5V295,880 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | M12 4 pin Female | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Absolute | 15 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 10 g (20 to 2000 Hz) | 70 g | - | |
PX119A-300G5V295,880 원10 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | DIN 43650 C (solenoid valve) | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Gauge | 300 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.009% FS/°F | 0.009% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX119A-500G5V295,880 원10 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | DIN 43650 C (solenoid valve) | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Gauge | 500 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.011% FS/°F | 0.011% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX119A-200G5V295,880 원10 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | DIN 43650 C (solenoid valve) | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Gauge | 200 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.009% FS/°F | 0.009% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX119A-100G5V295,880 원5 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | DIN 43650 C (solenoid valve) | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Gauge | 100 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX119A-100A5V295,880 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | DIN 43650 C (solenoid valve) | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Absolute | 100 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX119A-060G5V가격 문의12 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | DIN 43650 C (solenoid valve) | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Gauge | 60 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX119A-060A5V가격 문의12 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | DIN 43650 C (solenoid valve) | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Absolute | 60 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 20 g (20 to 500 Hz) | 70 g | - | |
PX119A-030A5V295,880 원10 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | DIN 43650 C (solenoid valve) | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Absolute | 30 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 10 g (20 to 2000 Hz) | 70 g | - | |
PX119A-030G5V295,880 원12 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | 0.50% BFSL Accuracy | 85 °C | 0 °C | DIN 43650 C (solenoid valve) | 0 to 5 V | 304 Stainless Steel | IP65 | 304 Stainless Steel, Alumina, Buna-N (NBR) | Gauge | 30 psi | 0 psi | 135 °C | -40 °C | Voltage | Supply + | Supply - | 1/8 in | NPT Male | Overvoltage, short circuit, reverse polarity | 1 ms | <0.3% FS | 8 to 30 Vdc | 0.01% FS/°F | 0.01% FS/°F | 10 g (20 to 2000 Hz) | 70 g | - |
스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.
