고정밀 압력 변환기 및 장기 안정성
필터 또는 검색 기능을 사용하여 원하시는 모델을 찾으십시오.
총 143개의 상품 · 1 - 20 표시
| 제품 번호 / 가격 | Brand | Accuracy | Accuracy Class | Accuracy Detail | Additional Features 1 | Applications | Burst Pressure | Burst Pressure Note | Compensated Temperature, Max | Compensated Temperature, Min | Electrical Connection | Electrical Output | Electrical Output Note | Electrostatic Discharge | Input Resistance | Insulation Resistance | Loop Resistance, Max | Materials, Wetted | Mating Connector | Measurement Pressure Type | Measurement Pressure, Max | Measurement Pressure, Min | Natural frequency | Operating Temperature, Max | Operating Temperature, Min | Output Resistance | Output Signal | Process Connection Size | Process Connection Type | Proof Pressure | Proof Pressure Note | Sensing Element | Sensing Element Note | Shock | Supply Voltage | Thermal Effect on Span error, Max | Thermal Effect on Zero error, Max | Vibration Sensitivity | Vibration Sensitivity Note | Weight | Stability | Stability Note | Current Draw | Supply Power Note | Zero/Balance Error | 수량 / 장바구니 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PXM5500MC0-1.60BARA10E가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.15 % | < 0.1% | Combined linearity,hysteresis and repeatability: ± 0.15% FS 70 bar (1000 psi) and above | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | Cable | 0 to 10 V | 10 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Absolute | 1.6 bar | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | BSPP Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PXM5500MC0-250BARG10E가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.15 % | 0.1% to 0.25% | Combined linearity,hysteresis and repeatability: ± 0.15% FS 70 bar (1000 psi) and above | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | Cable | 0 to 10 V | 10 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 250 bar | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | BSPP Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PXM5500MC1-250BARGI가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.1 % | 0.1% to 0.25% | (Combined Linearity, Hysteresis and Repeatability):± 0.10% FS (BFSL) <1000 psi | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Industrial and Manufacturing, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 4 to 20 mA | 4 to 20 mA ± 0.8 mA adj | Protected to 15 kV | None | 100 MΩ | 50 (V – 10) Ω max, where V is supply voltage (40 Vdc max) | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 250 bar | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 85 °C | -40 °C | None | Millivolt | 1/4 in | BSPP Male | 2x Full Scale | 2 times rated pressure or 15,000 psi, whichever is less, will not cause changes in performance beyond the specified tolerance | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | Qualification level of 100 g, 11 ms, half sine wave without damage | 10 Vdc | ± 0.02% FS/°F | ± 0.02% FS/°F, ± 0.02% FS/°F | 0.04% FS/g | At 20 g peak sinusoidal vibration from 10 to 2000 Hz(1⁄2” D.A.), the output shall not exceed 0.04% FS/g for 15 psi range, decreasing to 0.003% FS/g for 1000 psi and above | 200 g | - | - | - | - | - | |
PXM5500MD1-004BARGV가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.1 % | < 0.1% | Combined linearity,hysteresis and repeatability: ± 0.10% FSO (BFSL) <1000 psi | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Industrial and Manufacturing, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 3 mV/V | 30 mV typ, 26 mV min | Protected to 15 kV | 2500 Ω | 500 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 4 bar | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 150 °C | -54 °C | 2500 Ω | Millivolt | 1/4 in | BSPP Female | 2x Full Scale | 2 times rated pressure or 15,000 psi, whichever is less, will not cause changes in performance beyond the specified tolerance | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | Qualification level of 100 g, 11 ms, half sine wave without damage | 10 Vdc | ± 0.0025% FSO/°F | ± 0.0025% FSO/°F, ± 0.0025% FSO/°F | 0.04% FSO/g | At 35 g peak sinusoidal vibration from 10 Hz to 2000 Hz (1⁄2” D.A.), the output shall not exceed 0.04% FSO/g for 15 psi range, decreasing to 0.003% FSO/g for 1000 psi and above | 200 g | ± 0.1% | ± 0.1% for 18 months Calibration Stability | - | - | - | |
PXM5500MC0-600BARGV1,770,650 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.15 % | < 0.1% | Combined linearity,hysteresis and repeatability: ± 0.15% FSO 1000 psi and above | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Industrial and Manufacturing, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | Cable | 3 mV/V | 30 mV typ, 26 mV min | Protected to 15 kV | 2500 Ω | 500 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 600 bar | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 150 °C | -54 °C | 2500 Ω | Millivolt | 1/4 in | BSPP Male | 2x Full Scale | 2 times rated pressure or 15,000 psi, whichever is less, will not cause changes in performance beyond the specified tolerance | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | Qualification level of 100 g, 11 ms, half sine wave without damage | 10 Vdc | ± 0.0025% FSO/°F | ± 0.0025% FSO/°F, ± 0.0025% FSO/°F | 0.04% FSO/g | At 35 g peak sinusoidal vibration from 10 Hz to 2000 Hz (1⁄2” D.A.), the output shall not exceed 0.04% FSO/g for 15 psi range, decreasing to 0.003% FSO/g for 1000 psi and above | 200 g | ± 0.1% | ± 0.1% for 18 months Calibration Stability | - | - | - | |
PXM5500MC0-001BARGI2,239,860 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.1 % | < 0.1% | (Combined Linearity, Hysteresis and Repeatability):± 0.10% FS (BFSL) <1000 psi | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Industrial and Manufacturing, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure or 20,000 psi, whichever is less, will not cause rupture of the pressure containment cavity | 82 °C | -18 °C | MIL-26482-I 10-6P | 4 to 20 mA | 4 to 20 mA ± 0.8 mA adj | Protected to 15 kV | 2500 Ω typical,800 Ω min, 3000 Ω max.For 350 Ω bridge models see Custom Configurations. | 500 MΩ | 50 (V – 10) Ω max, where V is supply voltage (40 Vdc max) | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 1 bar | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 150 °C | -54 °C | 2500 Ω typical,800 Ω min,3000 Ω maximum. | Millivolt | 1/4 in | BSPP Male | 2x Full Scale | 2 times rated pressure or 15,000 psi, whichever is less, will not cause changes in performance beyond the specified tolerance | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | Qualification level of 100 g, 11 ms, half sine wave without damage | 10 Vdc | ± 0.0025% FSO/°F | ± 0.0025% FSO/°F, ± 0.0025% FSO/°F | 0.04% FSO/g | At 35 g peak sinusoidal vibration from 10 Hz to 2000 Hz (1⁄2” D.A.), the output shall not exceed 0.04% FSO/g for 15 psi range, decreasing to 0.003% FSO/g for 1000 psi and above | 200 g | ± 0.1% | ± 0.1% for 18 months | - | - | - | |
PXM5500MA6-006BARAI가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.1 % | < 0.1% | (Combined Linearity, Hysteresis and Repeatability):± 0.10% FS (BFSL) <1000 psi | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | DIN 43650 C (solenoid valve) | 4 to 20 mA | 4 to 20 mA ± 0.8 mA adj | Protected to 15 kV | None | 100 MΩ | 50 (V – 10) Ω max, where V is supply voltage (40 Vdc max) | 17-4 Stainless Steel | MIL-26482-I 10-6S | Absolute | 6 bar | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 85 °C | -40 °C | None | Current | 1/4 in | BSPP Male | 2x Full Scale | 2 times rated pressure or 15,000 psi, whichever is less, will not cause changes in performance beyond the specified tolerance | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | Qualification level of 100 g, 11 ms, half sine wave without damage | 10 to 40 Vdc | ± 0.02% FS/°F | ± 0.02% FS/°F, ± 0.02% FS/°F | 0.04% FS/g | At 20 g peak sinusoidal vibration from 10 to 2000 Hz(1⁄2” D.A.), the output shall not exceed 0.04% FS/g for 15 psi range, decreasing to 0.003% FS/g for 1000 psi and above | 225 g | - | - | 20 mA max with no load | 10 to 40 Vdc unregulated, reverse polarity protected | 4 mA ± 0.4 mA adj | |
PX5500L1-1.5BARA5E가격 문의12 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.15 % | < 0.1% | Combined linearity,hysteresis and repeatability: ± 0.15% FS 70 bar (1000 psi) and above | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 0 to 5 V | 5 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Absolute | 1.5 bar | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | AS5205/MS33656-4 Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PX5500L1-2.5KA10E가격 문의72 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.1 % | 0.1% to 0.25% | Combined linearity,hysteresis and repeatability: ± 0.10% FS (BFSL) <70 bar (<1000 psi) | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 0 to 10 V | 10 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Absolute | 2500 psi | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | AS5205/MS33656-4 Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PX5500L1-1.5KA10E가격 문의72 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.1 % | 0.1% to 0.25% | Combined linearity,hysteresis and repeatability: ± 0.10% FS (BFSL) <70 bar (<1000 psi) | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 0 to 10 V | 10 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Absolute | 1500 psi | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | AS5205/MS33656-4 Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PX5500L1-7.5KS5E가격 문의74 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.15 % | 0.1% to 0.25% | Combined linearity,hysteresis and repeatability: ± 0.15% FS 70 bar (1000 psi) and above | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 0 to 5 V | 5 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Sealed Gauge | 7500 psi | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | AS5205/MS33656-4 Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PX5500C0-2.5KA10E가격 문의74 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.15 % | 0.1% to 0.25% | Combined linearity,hysteresis and repeatability: ± 0.15% FS 70 bar (1000 psi) and above | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | Cable | 0 to 10 V | 10 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Absolute | 2500 psi | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | NPT Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PX5500L1-2.5KA5E가격 문의72 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.15 % | 0.1% to 0.25% | Combined linearity,hysteresis and repeatability: ± 0.15% FS 70 bar (1000 psi) and above | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 0 to 5 V | 5 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Absolute | 2500 psi | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | AS5205/MS33656-4 Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PX5500L1-2.00S5E가격 문의12 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.15 % | < 0.1% | Combined linearity,hysteresis and repeatability: ± 0.15% FS 70 bar (1000 psi) and above | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 0 to 5 V | 5 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Sealed Gauge | 2 psi | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | AS5205/MS33656-4 Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PX5500L1-10KS10E가격 문의74 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.1 % | 0.1% to 0.25% | Combined linearity,hysteresis and repeatability: ± 0.10% FS (BFSL) <70 bar (<1000 psi) | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 0 to 10 V | 10 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Sealed Gauge | 10000 psi | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | AS5205/MS33656-4 Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PX5500L1-1.5KG5E가격 문의74 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.15 % | 0.1% to 0.25% | Combined linearity,hysteresis and repeatability: ± 0.15% FS 70 bar (1000 psi) and above | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 0 to 5 V | 5 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 1500 psi | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | AS5205/MS33656-4 Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PX5500L1-1.5KA5E가격 문의72 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.15 % | 0.1% to 0.25% | Combined linearity,hysteresis and repeatability: ± 0.15% FS 70 bar (1000 psi) and above | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 0 to 5 V | 5 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Absolute | 1500 psi | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | AS5205/MS33656-4 Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PX5500D1-050G10E가격 문의74 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.1 % | < 0.1% | Combined linearity,hysteresis and repeatability: ± 0.10% FS (BFSL) <70 bar (<1000 psi) | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 0 to 10 V | 10 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 50 psi | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | NPT Female | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PX5500C1-500A10E가격 문의74 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.1 % | < 0.1% | Combined linearity,hysteresis and repeatability: ± 0.10% FS (BFSL) <70 bar (<1000 psi) | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 0 to 10 V | 10 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Absolute | 500 psi | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | NPT Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj | |
PX5500C1-2.5KA5E가격 문의74 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.15 % | 0.1% to 0.25% | Combined linearity,hysteresis and repeatability: ± 0.15% FS 70 bar (1000 psi) and above | None | Aeronautics and Aerospace, Automotive, Fluid Measurement and Control, Hydraulic and Pneumatic Systems, Laboratories and Scientific | 3x Full Scale | 3 times rated pressure | 82 °C | -18 °C | MIL-26482-I 10-6P | 0 to 5 V | 5 Vdc ± 0.1 Vdc ± 10% adj | Protected to 15 kV | None | 100 MΩ | - | 17-4 Stainless Steel | MIL-26482-I 10-6S | Absolute | 2500 psi | 0 psi | 5 kHz for 1 bar (15 psi), increasing logarithmically to 50 kHz for 5000 psi | 121 °C | -54 °C | 100 Ω | Voltage | 1/4 in | NPT Male | 2x Full Scale | - | 4-active-arm Strain Gauge Bridge | 4-active-arm bridge using sputter-deposited thin-film elements | None | 16 to 38 Vdc | ± 0.015% FS/°F (0.027%/ºC) | ± 0.015% FS/°F (0.027%/ºC), ± 0.015% FS/°F (0.027%/ºC) | None | - | 225 g | - | - | 20 mA max with no load | 16 to 38 Vdc unregulated | 0 Vdc ± 0.1 Vdc ± 5% adj |
