완전 플러시 다이어프램 압력 변환기
필터 또는 검색 기능을 사용하여 원하시는 모델을 찾으십시오.
총 45개의 상품 · 1 - 20 표시
| 제품 번호 / 가격 | Brand | Accuracy | Accuracy Class | Accuracy Detail | Burst Pressure | Burst Pressure Note | Compensated Temperature, Max | Compensated Temperature, Min | Electrical Connection | Electrical Output | Materials, Wetted | Mating Connector | Measurement Pressure Type | Measurement Pressure, Max | Measurement Pressure, Min | Operating Temperature, Max | Operating Temperature, Min | Output Signal | Process Connection Type | Proof Pressure | Proof Pressure Note | Supply Voltage | Thermal Effect on Span error, Max | Thermal Effect on Zero error, Max | Zero/Balance Error | 수량 / 장바구니 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PX103U1-500G5V1,802,960 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | MIL-26482-I 10-6P | 0.5 to 5.5 V | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 500 psi | 0 psi | 121 °C | -45 °C | Voltage | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 0.5V ± 0.1V | |
PX103U1-20KG5V1,802,960 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | MIL-26482-I 10-6P | 0.5 to 5.5 V | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 20000 psi | 0 psi | 121 °C | -45 °C | Voltage | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 0.5V ± 0.1V | |
PX103U1-200G5V1,802,960 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | MIL-26482-I 10-6P | 0.5 to 5.5 V | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 200 psi | 0 psi | 121 °C | -45 °C | Voltage | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 0.5V ± 0.1V | |
PX103U1-100G5V1,802,960 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | MIL-26482-I 10-6P | 0.5 to 5.5 V | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 100 psi | 0 psi | 121 °C | -45 °C | Voltage | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 0.5V ± 0.1V | |
PX103U1-025A5V가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 1 % | > 0.25% | ± 1% FSO linearity, hysteresis and repeatability combined | 5x Full Scale | 500% of rated pressure | 54 °C | -1 °C | MIL-26482-I 10-6P | 0.5 to 5.5 V | 316 Stainless Steel | MIL-26482-I 10-6S | Absolute | 25 psi | 0 psi | 93 °C | -45 °C | Voltage | Flush diaphragm | 2x Full Scale | 200% of rated pressure | 10 to 30 Vdc | <± 2% | <± 2%, <± 1% | 0.5V ± 0.1V | |
PX103U1-025G5V가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 1 % | > 0.25% | ± 1% FSO linearity, hysteresis and repeatability combined | 5x Full Scale | 500% of rated pressure | 54 °C | -1 °C | MIL-26482-I 10-6P | 0.5 to 5.5 V | 316 Stainless Steel | MIL-26482-I 10-6S | Gauge | 25 psi | 0 psi | 93 °C | -45 °C | Voltage | Flush diaphragm | 2x Full Scale | 200% of rated pressure | 10 to 30 Vdc | <± 2% | <± 2%, <± 1% | 0.5V ± 0.1V | |
PX103U0-500G5V가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | Cable | 0.5 to 5.5 V | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 500 psi | 0 psi | 121 °C | -45 °C | Voltage | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 0.5V ± 0.1V | |
PX103U0-200G5V가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | Cable | 0.5 to 5.5 V | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 200 psi | 0 psi | 121 °C | -45 °C | Voltage | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 0.5V ± 0.1V | |
PX103U0-050G5V1,610,870 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 1 % | > 0.25% | ± 1% FSO linearity, hysteresis and repeatability combined | 5x Full Scale | 500% of rated pressure | 54 °C | -1 °C | Cable | 0.5 to 5.5 V | 316 Stainless Steel | MIL-26482-I 10-6S | Gauge | 50 psi | 0 psi | 93 °C | -45 °C | Voltage | Flush diaphragm | 2x Full Scale | 200% of rated pressure | 10 to 30 Vdc | <± 2% | <± 2%, <± 1% | 0.5V ± 0.1V | |
PX103U0-100G5V가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | Cable | 0.5 to 5.5 V | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 100 psi | 0 psi | 121 °C | -45 °C | Voltage | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 0.5V ± 0.1V | |
PX103U0-025A5V가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 1 % | > 0.25% | ± 1% FSO linearity, hysteresis and repeatability combined | 5x Full Scale | 500% of rated pressure | 54 °C | -1 °C | Cable | 0.5 to 5.5 V | 316 Stainless Steel | MIL-26482-I 10-6S | Absolute | 25 psi | 0 psi | 93 °C | -45 °C | Voltage | Flush diaphragm | 2x Full Scale | 200% of rated pressure | 10 to 30 Vdc | <± 2% | <± 2%, <± 1% | 0.5V ± 0.1V | |
PX103U0-025G5V가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 1 % | > 0.25% | ± 1% FSO linearity, hysteresis and repeatability combined | 5x Full Scale | 500% of rated pressure | 54 °C | -1 °C | Cable | 0.5 to 5.5 V | 316 Stainless Steel | MIL-26482-I 10-6S | Gauge | 25 psi | 0 psi | 93 °C | -45 °C | Voltage | Flush diaphragm | 2x Full Scale | 200% of rated pressure | 10 to 30 Vdc | <± 2% | <± 2%, <± 1% | 0.5V ± 0.1V | |
PX103U1-500SI가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | MIL-26482-I 10-6P | 4 to 20 mA | 17-4 Stainless Steel | MIL-26482-I 10-6S | Sealed Gauge | 500 psi | 0 psi | 121 °C | -46 °C | Current | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 4 mA ± 0.2 mA | |
PX103U1-500GI1,812,970 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | MIL-26482-I 10-6P | 4 to 20 mA | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 500 psi | 0 psi | 121 °C | -46 °C | Current | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 4 mA ± 0.2 mA | |
PX103U1-3KG5V1,802,960 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | MIL-26482-I 10-6P | 0.5 to 5.5 V | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 3000 psi | 0 psi | 121 °C | -45 °C | Voltage | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 0.5V ± 0.1V | |
PX103U1-500AI가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | MIL-26482-I 10-6P | 4 to 20 mA | 17-4 Stainless Steel | MIL-26482-I 10-6S | Absolute | 500 psi | 0 psi | 121 °C | -46 °C | Current | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 4 mA ± 0.2 mA | |
PX103U1-2KG5V1,802,960 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | MIL-26482-I 10-6P | 0.5 to 5.5 V | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 2000 psi | 0 psi | 121 °C | -45 °C | Voltage | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 0.5V ± 0.1V | |
PX103U1-20KGI1,802,960 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | MIL-26482-I 10-6P | 4 to 20 mA | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 20000 psi | 0 psi | 121 °C | -46 °C | Current | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 4 mA ± 0.2 mA | |
PX103U1-200SI가격 문의20 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | MIL-26482-I 10-6P | 4 to 20 mA | 17-4 Stainless Steel | MIL-26482-I 10-6S | Sealed Gauge | 200 psi | 0 psi | 121 °C | -46 °C | Current | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 4 mA ± 0.2 mA | |
PX103U1-1KG5V1,802,960 원18 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | ± 0.5 % | > 0.25% | ± 0.5% FSO linearity, hysteresis and repeatability combined | 3x Full Scale | 300% of rated pressure, 50,000 psi maximum | 66 °C | -18 °C | MIL-26482-I 10-6P | 0.5 to 5.5 V | 17-4 Stainless Steel | MIL-26482-I 10-6S | Gauge | 1000 psi | 0 psi | 121 °C | -45 °C | Voltage | Flush diaphragm | 150% Full Scale | 200% of rated pressure | 10 to 30 Vdc | ± 0.003% rdg/°F | ± 0.003% rdg/°F, ± 0.0045% FSO/°F | 0.5V ± 0.1V |
스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.
