디지털 소형 압력 스위치(디스플레이 포함)
필터 또는 검색 기능을 사용하여 원하시는 모델을 찾으십시오.
총 12개의 상품
| 제품 번호 / 가격 | Brand | Acceleration, Max | Accuracy | Accuracy Detail | Burst Pressure | Control Output | Deadband | Deadband Type | Display | Electrical Connection | Materials | Measurement Pressure Type | Measurement Pressure, Max | Measurement Pressure, Min | Media Compatibility | Number of Digits | Operating Temperature, Max | Operating Temperature, Min | Operating and Storage Humidity | Output Detail | Output Signal | Process Connection Size | Process Connection Type | Process Temperature, Max | Process Temperature, Min | Repeatability | Repeatability Note | Response Time | Setpoint Repeatability | Shock | Storage Temperature, Max | Storage Temperature, Min | Supply Power Note | Switch | Switch Type | Temperature Accuracy | Vibration | Weight | 수량 / 장바구니 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PSWM1110-150GP5V163,540 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | 10g (98 m/s²) | ± 1 % | ± 1% FS | 300 psi Maximum | PNP | 0 to 150 psi | Adjustable | LED Display | Cable | ABS, Zinc Alloy | Gauge | 150 psi | 0 psi | Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen | 4 | 60 °C | -10 °C | 35 to 85% RH | 0 to 5 Vdc, 2 PNP | Voltage | 1/8 in | BSPT Male | 100 °C | 0 °C | ± 1% | ± 1% FS | 135 ms | ± 1% FS | 100g (980 m/s²) | 70 °C | -20 °C | Current Consumption ≤80 mA | Dual | PNP | ± 2 °C | 10 to 500 Hz freq., 0.06” (1.5 mm) amplitude | 80 g | |
PSWM1110-15VP5V163,540 원11 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | 10g (98 m/s²) | ± 1 % | ± 1% FS | 300 psi Maximum | PNP | 0 to 15 psi | Adjustable | LED Display | Cable | ABS, Zinc Alloy | Vacuum | 0 psi | -15 psi | Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen | 4 | 60 °C | -10 °C | 35 to 85% RH | 0 to 5 Vdc, 2 PNP | Voltage | 1/8 in | BSPT Male | 100 °C | 0 °C | ± 1% | ± 1% FS | 135 ms | ± 1% FS | 100g (980 m/s²) | 70 °C | -20 °C | Current Consumption ≤80 mA | Dual | PNP | ± 2 °C | 10 to 500 Hz freq., 0.06” (1.5 mm) amplitude | 80 g | |
PSWM1110-15CP5V163,540 원11 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | 10g (98 m/s²) | ± 1 % | ± 1% FS | 300 psi Maximum | PNP | -15 to 15 psi | Adjustable | LED Display | Cable | ABS, Zinc Alloy | Compound Gauge | 15 psi | -15 psi | Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen | 4 | 60 °C | -10 °C | 35 to 85% RH | 0 to 5 Vdc, 2 PNP | Voltage | 1/8 in | BSPT Male | 100 °C | 0 °C | ± 1% | ± 1% FS | 135 ms | ± 1% FS | 100g (980 m/s²) | 70 °C | -20 °C | Current Consumption ≤80 mA | Dual | PNP | ± 2 °C | 10 to 500 Hz freq., 0.06” (1.5 mm) amplitude | 80 g | |
PSWM1110-150GPI163,540 원11 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | 10g (98 m/s²) | ± 1 % | ± 1% FS | 300 psi Maximum | PNP | 0 to 150 psi | Adjustable | LED Display | Cable | ABS, Zinc Alloy | Gauge | 150 psi | 0 psi | Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen | 4 | 60 °C | -10 °C | 35 to 85% RH | 4 to 20 mA, 2 PNP | Current | 1/8 in | BSPT Male | 100 °C | 0 °C | ± 1% | ± 1% FS | 135 ms | ± 1% FS | 100g (980 m/s²) | 70 °C | -20 °C | Current Consumption ≤80 mA | Dual | PNP | ± 2 °C | 10 to 500 Hz freq., 0.06” (1.5 mm) amplitude | 80 g | |
PSWM1110-15VPI163,540 원11 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | 10g (98 m/s²) | ± 1 % | ± 1% FS | 300 psi Maximum | PNP | 0 to 15 psi | Adjustable | LED Display | Cable | ABS, Zinc Alloy | Vacuum | 0 psi | -15 psi | Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen | 4 | 60 °C | -10 °C | 35 to 85% RH | 4 to 20 mA, 2 PNP | Current | 1/8 in | BSPT Male | 100 °C | 0 °C | ± 1% | ± 1% FS | 135 ms | ± 1% FS | 100g (980 m/s²) | 70 °C | -20 °C | Current Consumption ≤80 mA | Dual | PNP | ± 2 °C | 10 to 500 Hz freq., 0.06” (1.5 mm) amplitude | 80 g | |
PSW1110-150GP5V163,540 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | 10g (98 m/s²) | ± 1 % | ± 1% FS | 300 psi Maximum | PNP | 0 to 150 psi | Adjustable | LED Display | Cable | ABS, Zinc Alloy | Gauge | 150 psi | 0 psi | Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen | 4 | 60 °C | -10 °C | 35 to 85% RH | 0 to 5 Vdc, 2 PNP | Voltage | 1/8 in | NPT Male | 100 °C | 0 °C | ± 1% | ± 1% FS | 135 ms | ± 1% FS | 100g (980 m/s²) | 70 °C | -20 °C | Current Consumption ≤80 mA | Dual | PNP | ± 2 °C | 10 to 500 Hz freq., 0.06” (1.5 mm) amplitude | 80 g | |
PSWM1110-15CPI163,540 원11 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | 10g (98 m/s²) | ± 1 % | ± 1% FS | 300 psi Maximum | PNP | -15 to 15 psi | Adjustable | LED Display | Cable | ABS, Zinc Alloy | Compound Gauge | 15 psi | -15 psi | Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen | 4 | 60 °C | -10 °C | 35 to 85% RH | 4 to 20 mA, 2 PNP | Current | 1/8 in | BSPT Male | 100 °C | 0 °C | ± 1% | ± 1% FS | 135 ms | ± 1% FS | 100g (980 m/s²) | 70 °C | -20 °C | Current Consumption ≤80 mA | Dual | PNP | ± 2 °C | 10 to 500 Hz freq., 0.06” (1.5 mm) amplitude | 80 g | |
PSW1110-15VP5V163,540 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | 10g (98 m/s²) | ± 1 % | ± 1% FS | 300 psi Maximum | PNP | 0 to 15 psi | Adjustable | LED Display | Cable | ABS, Zinc Alloy | Vacuum | 0 psi | -15 psi | Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen | 4 | 60 °C | -10 °C | 35 to 85% RH | 0 to 5 Vdc, 2 PNP | Voltage | 1/8 in | NPT Male | 100 °C | 0 °C | ± 1% | ± 1% FS | 135 ms | ± 1% FS | 100g (980 m/s²) | 70 °C | -20 °C | Current Consumption ≤80 mA | Dual | PNP | ± 2 °C | 10 to 500 Hz freq., 0.06” (1.5 mm) amplitude | 80 g | |
PSW1110-15CP5V163,540 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | 10g (98 m/s²) | ± 1 % | ± 1% FS | 300 psi Maximum | PNP | -15 to 15 psi | Adjustable | LED Display | Cable | ABS, Zinc Alloy | Compound Gauge | 15 psi | -15 psi | Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen | 4 | 60 °C | -10 °C | 35 to 85% RH | 0 to 5 Vdc, 2 PNP | Voltage | 1/8 in | NPT Male | 100 °C | 0 °C | ± 1% | ± 1% FS | 135 ms | ± 1% FS | 100g (980 m/s²) | 70 °C | -20 °C | Current Consumption ≤80 mA | Dual | PNP | ± 2 °C | 10 to 500 Hz freq., 0.06” (1.5 mm) amplitude | 80 g | |
PSW1110-15VPI163,540 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | 10g (98 m/s²) | ± 1 % | ± 1% FS | 300 psi Maximum | PNP | 0 to 15 psi | Adjustable | LED Display | Cable | ABS, Zinc Alloy | Vacuum | 0 psi | -15 psi | Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen | 4 | 60 °C | -10 °C | 35 to 85% RH | - | N/A | 1/8 in | NPT Male | 100 °C | 0 °C | ± 1% | ± 1% FS | 135 ms | ± 1% FS | 100g (980 m/s²) | 70 °C | -20 °C | Current Consumption ≤80 mA | Dual | PNP | ± 2 °C | 10 to 500 Hz freq., 0.06” (1.5 mm) amplitude | 80 g | |
PSW1110-150GPI163,540 원11 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | 10g (98 m/s²) | ± 1 % | ± 1% FS | 300 psi Maximum | PNP | 0 to 150 psi | Adjustable | LED Display | Cable | ABS, Zinc Alloy | Gauge | 150 psi | 0 psi | Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen | 4 | 60 °C | -10 °C | 35 to 85% RH | 4 to 20 mA, 2 PNP | Current | 1/8 in | NPT Male | 100 °C | 0 °C | ± 1% | ± 1% FS | 135 ms | ± 1% FS | 100g (980 m/s²) | 70 °C | -20 °C | Current Consumption ≤80 mA | Dual | PNP | ± 2 °C | 10 to 500 Hz freq., 0.06” (1.5 mm) amplitude | 80 g | |
PSW1110-15CPI163,540 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | 10g (98 m/s²) | ± 1 % | ± 1% FS | 300 psi Maximum | PNP | -15 to 15 psi | Adjustable | LED Display | Cable | ABS, Zinc Alloy | Compound Gauge | 15 psi | -15 psi | Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen | 4 | 60 °C | -10 °C | 35 to 85% RH | 4 to 20 mA, 2 PNP | Current | 1/8 in | NPT Male | 100 °C | 0 °C | ± 1% | ± 1% FS | 135 ms | ± 1% FS | 100g (980 m/s²) | 70 °C | -20 °C | Current Consumption ≤80 mA | Dual | PNP | ± 2 °C | 10 to 500 Hz freq., 0.06” (1.5 mm) amplitude | 80 g |
스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.
