Series-677B | Britestone

모델 보기

필터 또는 검색 기능을 사용하여 원하시는 모델을 찾으십시오.

총 12개의 상품

제품 번호 / 가격	Brand	Accuracy	Accuracy Detail	Applications	Compensated Temperature, Max	Compensated Temperature, Min	Compliance	Display Type	Electrical Output	Enclosure Ratings	Long Term Stability	Loop Resistance	Materials, Wetted	Measurement Pressure Type	Measurement Pressure, Max	Measurement Pressure, Min	Media Compatibility	Number of Wires	Operating Temperature, Max	Operating Temperature, Min	Output Signal	Process Connection Note	Process Connection Size	Process Connection Type	Proof Pressure	Response Time	Span Adjustment	Storage Temperature, Max	Storage Temperature, Min	Supply Power Type	Supply Voltage	Thermal Effects	Thermal Effects Note	Weight	Zero Setting Adjustable Range
677B-15가격 문의11 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 0.4 %	± 0.4% FS* at room temperature	Energy Management Systems, HVAC	85 °C	-18 °C	CE	N/A	4 to 20 mA	IP65, NEMA Type 4	± 1% FS/year	0 to 800 Ω	302 Stainless Steel, Brass, Glass, Nickel, Silicone	Differential	1 inH₂O	-1 inH₂O	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases	2	85 °C	-18 °C	Current	OD barbed brass pressure fitting	3/16 in	Barbed Fitting	Up to 15 psi	10 ms	Potentiometers	105 °C	-54 °C	DC	16 to 32 Vdc	<0.028% FS/°F	(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).	330 g	Internally accessible potentiometers, non interactive
677B-14가격 문의11 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 0.4 %	± 0.4% FS* at room temperature	Energy Management Systems, HVAC	85 °C	-18 °C	CE	N/A	4 to 20 mA	IP65, NEMA Type 4	± 1% FS/year	0 to 800 Ω	302 Stainless Steel, Brass, Glass, Nickel, Silicone	Differential	0.5 inH₂O	-0.5 inH₂O	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases	2	85 °C	-18 °C	Current	OD barbed brass pressure fitting	3/16 in	Barbed Fitting	Up to 15 psi	10 ms	Potentiometers	105 °C	-54 °C	DC	16 to 32 Vdc	<0.028% FS/°F	(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).	330 g	Internally accessible potentiometers, non interactive
677B-13가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 0.4 %	± 0.4% FS* at room temperature	Energy Management Systems, HVAC	85 °C	-18 °C	CE	N/A	4 to 20 mA	IP65, NEMA Type 4	± 1% FS/year	0 to 800 Ω	302 Stainless Steel, Brass, Glass, Nickel, Silicone	Differential	0.25 inH₂O	-0.25 inH₂O	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases	2	85 °C	-18 °C	Current	OD barbed brass pressure fitting	3/16 in	Barbed Fitting	Up to 15 psi	10 ms	Potentiometers	105 °C	-54 °C	DC	16 to 32 Vdc	<0.028% FS/°F	(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).	330 g	Internally accessible potentiometers, non interactive
677B-08가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 0.4 %	± 0.4% FS* at room temperature	Energy Management Systems, HVAC	85 °C	-18 °C	CE	N/A	4 to 20 mA	IP65, NEMA Type 4	± 1% FS/year	0 to 800 Ω	302 Stainless Steel, Brass, Glass, Nickel, Silicone	Differential	25 inH₂O	0 inH₂O	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases	2	85 °C	-18 °C	Current	OD barbed brass pressure fitting	3/16 in	Barbed Fitting	Up to 15 psi	10 ms	Potentiometers	105 °C	-54 °C	DC	16 to 32 Vdc	<0.028% FS/°F	(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).	330 g	Internally accessible potentiometers, non interactive
677B-12가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 0.4 %	± 0.4% FS* at room temperature	Energy Management Systems, HVAC	85 °C	-18 °C	CE	N/A	4 to 20 mA	IP65, NEMA Type 4	± 1% FS/year	0 to 800 Ω	302 Stainless Steel, Brass, Glass, Nickel, Silicone	Differential	0.1 inH₂O	-0.1 inH₂O	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases	2	85 °C	-18 °C	Current	OD barbed brass pressure fitting	3/16 in	Barbed Fitting	Up to 15 psi	10 ms	Potentiometers	105 °C	-54 °C	DC	16 to 32 Vdc	<0.028% FS/°F	(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).	330 g	Internally accessible potentiometers, non interactive
677B-07가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 0.4 %	± 0.4% FS* at room temperature	Energy Management Systems, HVAC	85 °C	-18 °C	CE	N/A	4 to 20 mA	IP65, NEMA Type 4	± 1% FS/year	0 to 800 Ω	302 Stainless Steel, Brass, Glass, Nickel, Silicone	Differential	10 inH₂O	0 inH₂O	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases	2	85 °C	-18 °C	Current	OD barbed brass pressure fitting	3/16 in	Barbed Fitting	Up to 15 psi	10 ms	Potentiometers	105 °C	-54 °C	DC	16 to 32 Vdc	<0.028% FS/°F	(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).	330 g	Internally accessible potentiometers, non interactive
677B-06가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 0.4 %	± 0.4% FS* at room temperature	Energy Management Systems, HVAC	85 °C	-18 °C	CE	N/A	4 to 20 mA	IP65, NEMA Type 4	± 1% FS/year	0 to 800 Ω	302 Stainless Steel, Brass, Glass, Nickel, Silicone	Differential	5 inH₂O	0 inH₂O	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases	2	85 °C	-18 °C	Current	OD barbed brass pressure fitting	3/16 in	Barbed Fitting	Up to 15 psi	10 ms	Potentiometers	105 °C	-54 °C	DC	16 to 32 Vdc	<0.028% FS/°F	(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).	330 g	Internally accessible potentiometers, non interactive
677B-04가격 문의11 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 0.4 %	± 0.4% FS* at room temperature	Energy Management Systems, HVAC	85 °C	-18 °C	CE	N/A	4 to 20 mA	IP65, NEMA Type 4	± 1% FS/year	0 to 800 Ω	302 Stainless Steel, Brass, Glass, Nickel, Silicone	Differential	1 inH₂O	0 inH₂O	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases	2	85 °C	-18 °C	Current	OD barbed brass pressure fitting	3/16 in	Barbed Fitting	Up to 15 psi	10 ms	Potentiometers	105 °C	-54 °C	DC	16 to 32 Vdc	<0.028% FS/°F	(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).	330 g	Internally accessible potentiometers, non interactive
677B-02가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 0.4 %	± 0.4% FS* at room temperature	Energy Management Systems, HVAC	85 °C	-18 °C	CE	N/A	4 to 20 mA	IP65, NEMA Type 4	± 1% FS/year	0 to 800 Ω	302 Stainless Steel, Brass, Glass, Nickel, Silicone	Differential	0.25 inH₂O	0 inH₂O	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases	2	85 °C	-18 °C	Current	OD barbed brass pressure fitting	3/16 in	Barbed Fitting	Up to 15 psi	10 ms	Potentiometers	105 °C	-54 °C	DC	16 to 32 Vdc	<0.028% FS/°F	(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).	330 g	Internally accessible potentiometers, non interactive
677B-03가격 문의11 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 0.4 %	± 0.4% FS* at room temperature	Energy Management Systems, HVAC	85 °C	-18 °C	CE	N/A	4 to 20 mA	IP65, NEMA Type 4	± 1% FS/year	0 to 800 Ω	302 Stainless Steel, Brass, Glass, Nickel, Silicone	Differential	0.5 inH₂O	0 inH₂O	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases	2	85 °C	-18 °C	Current	OD barbed brass pressure fitting	3/16 in	Barbed Fitting	Up to 15 psi	10 ms	Potentiometers	105 °C	-54 °C	DC	16 to 32 Vdc	<0.028% FS/°F	(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).	330 g	Internally accessible potentiometers, non interactive
677B-01가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 0.4 %	± 0.4% FS* at room temperature	Energy Management Systems, HVAC	85 °C	-18 °C	CE	N/A	4 to 20 mA	IP65, NEMA Type 4	± 1% FS/year	0 to 800 Ω	302 Stainless Steel, Brass, Glass, Nickel, Silicone	Differential	0.1 inH₂O	0 inH₂O	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases	2	85 °C	-18 °C	Current	OD barbed brass pressure fitting	3/16 in	Barbed Fitting	Up to 15 psi	10 ms	Potentiometers	105 °C	-54 °C	DC	16 to 32 Vdc	<0.028% FS/°F	(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).	330 g	Internally accessible potentiometers, non interactive
677B-05가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.	Dwyer a DwyerOmega Brand	± 0.4 %	± 0.4% FS* at room temperature	Energy Management Systems, HVAC	85 °C	-18 °C	CE	N/A	4 to 20 mA	IP65, NEMA Type 4	± 1% FS/year	0 to 800 Ω	302 Stainless Steel, Brass, Glass, Nickel, Silicone	Differential	2.5 inH₂O	0 inH₂O	Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases	2	85 °C	-18 °C	Current	OD barbed brass pressure fitting	3/16 in	Barbed Fitting	Up to 15 psi	10 ms	Potentiometers	105 °C	-54 °C	DC	16 to 32 Vdc	<0.028% FS/°F	(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).	330 g	Internally accessible potentiometers, non interactive

스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.

제품 번호 / 가격

Brand

Accuracy

Accuracy Detail

Applications

Compensated Temperature, Max

Compensated Temperature, Min

Compliance

Display Type

Electrical Output

Enclosure Ratings

Long Term Stability

Loop Resistance

Materials, Wetted

Measurement Pressure Type

Measurement Pressure, Max

Measurement Pressure, Min

Media Compatibility

Number of Wires

Operating Temperature, Max

Operating Temperature, Min

Output Signal

Process Connection Note

Process Connection Size

Process Connection Type

Proof Pressure

Response Time

Span Adjustment

Storage Temperature, Max

Storage Temperature, Min

Supply Power Type

Supply Voltage

Thermal Effects

Thermal Effects Note

Weight

Zero Setting Adjustable Range

수량 / 장바구니

677B-15가격 문의11 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 0.4 %

± 0.4% FS* at room temperature

Energy Management Systems, HVAC

85 °C

-18 °C

N/A

4 to 20 mA

IP65, NEMA Type 4

± 1% FS/year

0 to 800 Ω

302 Stainless Steel, Brass, Glass, Nickel, Silicone

Differential

1 inH₂O

-1 inH₂O

Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases

85 °C

-18 °C

Current

OD barbed brass pressure fitting

3/16 in

Barbed Fitting

Up to 15 psi

10 ms

Potentiometers

105 °C

-54 °C

16 to 32 Vdc

<0.028% FS/°F

(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).

330 g

Internally accessible potentiometers, non interactive

677B-14가격 문의11 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 0.4 %

± 0.4% FS* at room temperature

Energy Management Systems, HVAC

85 °C

-18 °C

N/A

4 to 20 mA

IP65, NEMA Type 4

± 1% FS/year

0 to 800 Ω

302 Stainless Steel, Brass, Glass, Nickel, Silicone

Differential

0.5 inH₂O

-0.5 inH₂O

Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases

85 °C

-18 °C

Current

OD barbed brass pressure fitting

3/16 in

Barbed Fitting

Up to 15 psi

10 ms

Potentiometers

105 °C

-54 °C

16 to 32 Vdc

<0.028% FS/°F

(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).

330 g

Internally accessible potentiometers, non interactive

677B-13가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 0.4 %

± 0.4% FS* at room temperature

Energy Management Systems, HVAC

85 °C

-18 °C

N/A

4 to 20 mA

IP65, NEMA Type 4

± 1% FS/year

0 to 800 Ω

302 Stainless Steel, Brass, Glass, Nickel, Silicone

Differential

0.25 inH₂O

-0.25 inH₂O

Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases

85 °C

-18 °C

Current

OD barbed brass pressure fitting

3/16 in

Barbed Fitting

Up to 15 psi

10 ms

Potentiometers

105 °C

-54 °C

16 to 32 Vdc

<0.028% FS/°F

(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).

330 g

Internally accessible potentiometers, non interactive

677B-08가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 0.4 %

± 0.4% FS* at room temperature

Energy Management Systems, HVAC

85 °C

-18 °C

N/A

4 to 20 mA

IP65, NEMA Type 4

± 1% FS/year

0 to 800 Ω

302 Stainless Steel, Brass, Glass, Nickel, Silicone

Differential

25 inH₂O

0 inH₂O

Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases

85 °C

-18 °C

Current

OD barbed brass pressure fitting

3/16 in

Barbed Fitting

Up to 15 psi

10 ms

Potentiometers

105 °C

-54 °C

16 to 32 Vdc

<0.028% FS/°F

(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).

330 g

Internally accessible potentiometers, non interactive

677B-12가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 0.4 %

± 0.4% FS* at room temperature

Energy Management Systems, HVAC

85 °C

-18 °C

N/A

4 to 20 mA

IP65, NEMA Type 4

± 1% FS/year

0 to 800 Ω

302 Stainless Steel, Brass, Glass, Nickel, Silicone

Differential

0.1 inH₂O

-0.1 inH₂O

Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases

85 °C

-18 °C

Current

OD barbed brass pressure fitting

3/16 in

Barbed Fitting

Up to 15 psi

10 ms

Potentiometers

105 °C

-54 °C

16 to 32 Vdc

<0.028% FS/°F

(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).

330 g

Internally accessible potentiometers, non interactive

677B-07가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 0.4 %

± 0.4% FS* at room temperature

Energy Management Systems, HVAC

85 °C

-18 °C

N/A

4 to 20 mA

IP65, NEMA Type 4

± 1% FS/year

0 to 800 Ω

302 Stainless Steel, Brass, Glass, Nickel, Silicone

Differential

10 inH₂O

0 inH₂O

Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases

85 °C

-18 °C

Current

OD barbed brass pressure fitting

3/16 in

Barbed Fitting

Up to 15 psi

10 ms

Potentiometers

105 °C

-54 °C

16 to 32 Vdc

<0.028% FS/°F

(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).

330 g

Internally accessible potentiometers, non interactive

677B-06가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 0.4 %

± 0.4% FS* at room temperature

Energy Management Systems, HVAC

85 °C

-18 °C

N/A

4 to 20 mA

IP65, NEMA Type 4

± 1% FS/year

0 to 800 Ω

302 Stainless Steel, Brass, Glass, Nickel, Silicone

Differential

5 inH₂O

0 inH₂O

Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases

85 °C

-18 °C

Current

OD barbed brass pressure fitting

3/16 in

Barbed Fitting

Up to 15 psi

10 ms

Potentiometers

105 °C

-54 °C

16 to 32 Vdc

<0.028% FS/°F

(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).

330 g

Internally accessible potentiometers, non interactive

677B-04가격 문의11 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 0.4 %

± 0.4% FS* at room temperature

Energy Management Systems, HVAC

85 °C

-18 °C

N/A

4 to 20 mA

IP65, NEMA Type 4

± 1% FS/year

0 to 800 Ω

302 Stainless Steel, Brass, Glass, Nickel, Silicone

Differential

1 inH₂O

0 inH₂O

Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases

85 °C

-18 °C

Current

OD barbed brass pressure fitting

3/16 in

Barbed Fitting

Up to 15 psi

10 ms

Potentiometers

105 °C

-54 °C

16 to 32 Vdc

<0.028% FS/°F

(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).

330 g

Internally accessible potentiometers, non interactive

677B-02가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 0.4 %

± 0.4% FS* at room temperature

Energy Management Systems, HVAC

85 °C

-18 °C

N/A

4 to 20 mA

IP65, NEMA Type 4

± 1% FS/year

0 to 800 Ω

302 Stainless Steel, Brass, Glass, Nickel, Silicone

Differential

0.25 inH₂O

0 inH₂O

Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases

85 °C

-18 °C

Current

OD barbed brass pressure fitting

3/16 in

Barbed Fitting

Up to 15 psi

10 ms

Potentiometers

105 °C

-54 °C

16 to 32 Vdc

<0.028% FS/°F

(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).

330 g

Internally accessible potentiometers, non interactive

677B-03가격 문의11 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 0.4 %

± 0.4% FS* at room temperature

Energy Management Systems, HVAC

85 °C

-18 °C

N/A

4 to 20 mA

IP65, NEMA Type 4

± 1% FS/year

0 to 800 Ω

302 Stainless Steel, Brass, Glass, Nickel, Silicone

Differential

0.5 inH₂O

0 inH₂O

Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases

85 °C

-18 °C

Current

OD barbed brass pressure fitting

3/16 in

Barbed Fitting

Up to 15 psi

10 ms

Potentiometers

105 °C

-54 °C

16 to 32 Vdc

<0.028% FS/°F

(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).

330 g

Internally accessible potentiometers, non interactive

677B-01가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 0.4 %

± 0.4% FS* at room temperature

Energy Management Systems, HVAC

85 °C

-18 °C

N/A

4 to 20 mA

IP65, NEMA Type 4

± 1% FS/year

0 to 800 Ω

302 Stainless Steel, Brass, Glass, Nickel, Silicone

Differential

0.1 inH₂O

0 inH₂O

Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases

85 °C

-18 °C

Current

OD barbed brass pressure fitting

3/16 in

Barbed Fitting

Up to 15 psi

10 ms

Potentiometers

105 °C

-54 °C

16 to 32 Vdc

<0.028% FS/°F

(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).

330 g

Internally accessible potentiometers, non interactive

677B-05가격 문의10 weeks리드타임은 상황에 따라 달라질 수 있습니다.

Dwyer a DwyerOmega Brand

± 0.4 %

± 0.4% FS* at room temperature

Energy Management Systems, HVAC

85 °C

-18 °C

N/A

4 to 20 mA

IP65, NEMA Type 4

± 1% FS/year

0 to 800 Ω

302 Stainless Steel, Brass, Glass, Nickel, Silicone

Differential

2.5 inH₂O

0 inH₂O

Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases

85 °C

-18 °C

Current

OD barbed brass pressure fitting

3/16 in

Barbed Fitting

Up to 15 psi

10 ms

Potentiometers

105 °C

-54 °C

16 to 32 Vdc

<0.028% FS/°F

(Includes zero and span) <0.028% FS/°F, 0 to 185°F (-18 to 85°C).

330 g

Internally accessible potentiometers, non interactive
