총 74개의 상품 · 1 - 20 표시

제품 번호 / 가격	Brand	Barrel Diameter	Heater Power	Insulator Type	Material Construction Option	Operating Temperature, Max	Power Density Note	Power Density, Max	Power Tolerance	Resistance Tolerance	Sensor Type	Supply Voltage	Termination	Voltage, Max	Width	Width Tolerance
MPP56001가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	2.5 in	400 W	N/A	Outrigger, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	58 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	1 in	± 3/32"
MPP56101가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	2.5 in	500 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	49 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	1.5 in	± 3/32"
MPP55801가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	2.25 in	1000 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	66 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	2.5 in	± 3/32"
MPP55401가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	2.25 in	350 W	N/A	Outrigger, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	58 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	1 in	± 3/32"
MPP55051380,110 원13 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	2 in	750 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	71 W/in²	+5%, -10%	+10%, -5%	N/A	120 Vac	None	480 Vac	2 in	± 3/32"
MPP55101가격 문의16 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	2 in	750 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	71 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	2 in	± 3/32"
MPP54901가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	2 in	400 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	50 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	1.5 in	± 3/32"
MPP54801가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	2 in	350 W	N/A	Outrigger, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	66 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	1 in	± 3/32"
MPP54601가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	1.75 in	1000 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	74 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	3 in	± 3/32"
MPP54701가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	2 in	350 W	N/A	Outrigger, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	66 W/in²	+5%, -10%	+10%, -5%	N/A	120 Vac	None	480 Vac	1 in	± 3/32"
MPP54401가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	1.75 in	550 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	49 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	2.5 in	± 3/32"
MPP54301가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	1.75 in	750 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	83 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	2 in	± 3/32"
MPP53801가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	1.75 in	300 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	44 W/in²	+5%, -10%	+10%, -5%	N/A	120 Vac	None	480 Vac	1.5 in	± 3/32"
MPP53901가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	1.75 in	300 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	44 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	1.5 in	± 3/32"
MPP53501가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	1.5 in	500 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	45 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	3 in	± 3/32"
MPP53401가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	1.5 in	350 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	31 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	3 in	± 3/32"
MPP53202가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	1.5 in	450 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	61 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	2 in	± 3/32"
MPP52903가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	1.5 in	450 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	81 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	1.5 in	± 3/32"
MPP53001가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	1.5 in	300 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	40 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	2 in	± 3/32"
MPP52602가격 문의15 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	1.5 in	300 W	N/A	Latch and Trunnion, One Pieace Band	760 °C	Nozzle Bands, Under 3" Diameter: 4.7 to 15.5 Watt/cm² (30 to 100 Watt/in²) Barrel Bands, 3" and Greater in Diameter:3.1 to 10.9 Watt/cm² (20 to 70 Watt/in²) Maximum Watt Density: 23 Watt/cm² (150 Watt/in²) dependent on heater size, operating temperature and termination	54 W/in²	+5%, -10%	+10%, -5%	N/A	240 Vac	None	480 Vac	1.5 in	± 3/32"
