총 11개의 상품

제품 번호 / 가격	Brand	Cable Length	Calibration Option	Electrical Connection	Electrical Output	End Rod	Force Type	Full Scale Deflection	Height	Hysteresis	Input Resistance	Interchangeability	Length	Linearity	Load Button	Load Cell Capacity	Load Cell Type	Materials	Operating Temperature, Max	Operating Temperature, Min	Output Resistance	Overload, Max	Process Temperature, Max	Process Temperature, Min	Repeatability	Safe Overload	Supply Power Note	Supply Voltage	Thermal Span Effect	Thermal Zero Effect	Weight	Width	Wire Gauge	Wiring/Connector Table	Zero/Balance Error	Mating Connector
LCM111-1.5K1,300,440 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	0 ft	5 POINT NIST	N/A	3 mV/V	MREC-M16M	Compression, Tension	0.02 in	51 mm	± 0.05%	350 ± 10 Ω	0.0025	89 mm	± 0.03%	MLBC-M16	1500 kgf	S-beam	17-4 PH Stainless Steel	93 °C	-40 °C	350 ± 10 Ω	300% FS	71 °C	17 °C	± 0.01%	150% FS	10 Vdc, 15 Vdc maximum	10 Vdc	0.0018% FSO/°C	0.0018% FSO/°C	1.6 kg	25 mm	-	Pin A: (+) Output; Pin B: (-) Output; Pin C: (-) Input; Pin D: (+) Input; Pin E: Not Connected; Pin F: Not Connected	± 1%	MIL-26482-I 10-6S
LCM101-1.5K1,282,970 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	15 ft	5 POINT NIST	Cable	3 mV/V	MREC-M16M	Compression, Tension	0.02 in	51 mm	± 0.05%	350 ± 10 Ω	0.0025	89 mm	± 0.03%	MLBC-M16	1500 kgf	S-beam	17-4 PH Stainless Steel	93 °C	-40 °C	350 ± 10 Ω	300% FS	71 °C	17 °C	± 0.01%	150% FS	10 Vdc, 15 Vdc maximum	10 Vdc	0.0018% FSO/°C	0.0018% FSO/°C	1.6 kg	25 mm	20 AWG	Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input	± 1%	-
LCM101-250가격 문의	OMEGA Engineering	15 ft	5 POINT NIST	Cable	3 mV/V	MREC-M12M	Compression, Tension	0.02 in	51 mm	± 0.05%	350 ± 10 Ω	0.0025	76 mm	± 0.03%	MLBC-M12	250 kgf	S-beam	17-4 PH Stainless Steel	93 °C	-40 °C	350 ± 10 Ω	300% FS	71 °C	17 °C	± 0.01%	150% FS	10 Vdc, 15 Vdc maximum	10 Vdc	0.0018% FSO/°C	0.0018% FSO/°C	1.1 kg	25 mm	20 AWG	Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input	± 1%	-
LCM101-5001,078,070 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	15 ft	5 POINT NIST	Cable	3 mV/V	MREC-M12M	Compression, Tension	0.02 in	51 mm	± 0.05%	350 ± 10 Ω	0.0025	76 mm	± 0.03%	MLBC-M12	500 kgf	S-beam	17-4 PH Stainless Steel	93 °C	-40 °C	350 ± 10 Ω	300% FS	71 °C	17 °C	± 0.01%	150% FS	10 Vdc, 15 Vdc maximum	10 Vdc	0.0018% FSO/°C	0.0018% FSO/°C	1.1 kg	25 mm	20 AWG	Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input	± 1%	-
LCM101-10K2,354,500 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	15 ft	5 POINT NIST	Cable	3 mV/V	MREC-M24M	Compression, Tension	0.02 in	76 mm	± 0.05%	350 ± 10 Ω	0.0025	108 mm	± 0.03%	MLBC-M24	10000 kgf	S-beam	17-4 PH Stainless Steel	93 °C	-40 °C	350 ± 10 Ω	300% FS	71 °C	17 °C	± 0.01%	150% FS	10 Vdc, 15 Vdc maximum	10 Vdc	0.0018% FSO/°C	0.0018% FSO/°C	2 kg	38 mm	20 AWG	Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input	± 1%	-
LCM101-1001,091,270 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	30 ft	5 POINT NIST	Cable	3 mV/V	MREC-M6M	Compression, Tension	0.02 in	38 mm	± 0.05%	350 ± 10 Ω	0.0025	64 mm	± 0.03%	MLBC-M6	100 kgf	S-beam	17-4 PH Stainless Steel	93 °C	-40 °C	350 ± 10 Ω	300% FS	71 °C	17 °C	± 0.01%	150% FS	10 Vdc, 15 Vdc maximum	10 Vdc	0.0018% FSO/°C	0.0018% FSO/°C	0.45 kg	13 mm	24 AWG	Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input	± 1%	-
LCM101-5K가격 문의	OMEGA Engineering	15 ft	5 POINT NIST	Cable	3 mV/V	MREC-M24M	Compression, Tension	0.02 in	76 mm	± 0.05%	350 ± 10 Ω	0.0025	108 mm	± 0.03%	MLBC-M24	5000 kgf	S-beam	17-4 PH Stainless Steel	93 °C	-40 °C	350 ± 10 Ω	300% FS	71 °C	17 °C	± 0.01%	150% FS	10 Vdc, 15 Vdc maximum	10 Vdc	0.0018% FSO/°C	0.0018% FSO/°C	2 kg	38 mm	20 AWG	Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input	± 1%	-
LCM101-501,078,070 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	30 ft	5 POINT NIST	Cable	3 mV/V	MREC-M6M	Compression, Tension	0.02 in	38 mm	± 0.05%	350 ± 10 Ω	0.0025	64 mm	± 0.03%	MLBC-M6	50 kgf	S-beam	17-4 PH Stainless Steel	93 °C	-40 °C	350 ± 10 Ω	300% FS	71 °C	17 °C	± 0.01%	150% FS	10 Vdc, 15 Vdc maximum	10 Vdc	0.0018% FSO/°C	0.0018% FSO/°C	0.45 kg	13 mm	24 AWG	Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input	± 1%	-
LCM101-251,117,870 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	30 ft	5 POINT NIST	Cable	3 mV/V	MREC-M6M	Compression, Tension	0.02 in	38 mm	± 0.05%	350 ± 10 Ω	0.0025	64 mm	± 0.03%	MLBC-M6	25 kgf	S-beam	17-4 PH Stainless Steel	93 °C	-40 °C	350 ± 10 Ω	300% FS	71 °C	17 °C	± 0.01%	150% FS	10 Vdc, 15 Vdc maximum	10 Vdc	0.0018% FSO/°C	0.0018% FSO/°C	0.45 kg	13 mm	24 AWG	Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input	± 1%	-
LCM101-101,157,690 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	30 ft	5 POINT NIST	Cable	3 mV/V	MREC-M6M	Compression, Tension	0.02 in	38 mm	± 0.05%	350 ± 10 Ω	0.0025	64 mm	± 0.03%	MLBC-M6	10 kgf	S-beam	17-4 PH Stainless Steel	93 °C	-40 °C	350 ± 10 Ω	300% FS	71 °C	17 °C	± 0.01%	150% FS	10 Vdc, 15 Vdc maximum	10 Vdc	0.0018% FSO/°C	0.0018% FSO/°C	0.45 kg	13 mm	24 AWG	Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input	± 1%	-
LCM101-1K가격 문의	OMEGA Engineering	15 ft	5 POINT NIST	Cable	3 mV/V	MREC-M12M	Compression, Tension	0.02 in	51 mm	± 0.05%	350 ± 10 Ω	0.0025	76 mm	± 0.03%	MLBC-M12	1000 kgf	S-beam	17-4 PH Stainless Steel	93 °C	-40 °C	350 ± 10 Ω	300% FS	71 °C	17 °C	± 0.01%	150% FS	10 Vdc, 15 Vdc maximum	10 Vdc	0.0018% FSO/°C	0.0018% FSO/°C	1.1 kg	25 mm	20 AWG	Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input	± 1%	-

스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.

제품 번호 / 가격

Brand

Cable Length

Calibration Option

Electrical Connection

Electrical Output

End Rod

Force Type

Full Scale Deflection

Height

Hysteresis

Input Resistance

Interchangeability

Length

Linearity

Load Button

Load Cell Capacity

Load Cell Type

Materials

Operating Temperature, Max

Operating Temperature, Min

Output Resistance

Overload, Max

Process Temperature, Max

Process Temperature, Min

Repeatability

Safe Overload

Supply Power Note

Supply Voltage

Thermal Span Effect

Thermal Zero Effect

Weight

Width

Wire Gauge

Wiring/Connector Table

Zero/Balance Error

Mating Connector

수량 / 장바구니

LCM111-1.5K1,300,440 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

0 ft

5 POINT NIST

N/A

3 mV/V

MREC-M16M

Compression, Tension

0.02 in

51 mm

± 0.05%

350 ± 10 Ω

0.0025

89 mm

± 0.03%

MLBC-M16

1500 kgf

S-beam

17-4 PH Stainless Steel

93 °C

-40 °C

350 ± 10 Ω

300% FS

71 °C

17 °C

± 0.01%

150% FS

10 Vdc, 15 Vdc maximum

10 Vdc

0.0018% FSO/°C

1.6 kg

25 mm

Pin A: (+) Output; Pin B: (-) Output; Pin C: (-) Input; Pin D: (+) Input; Pin E: Not Connected; Pin F: Not Connected

± 1%

MIL-26482-I 10-6S

LCM101-1.5K1,282,970 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

15 ft

5 POINT NIST

Cable

3 mV/V

MREC-M16M

Compression, Tension

0.02 in

51 mm

± 0.05%

350 ± 10 Ω

0.0025

89 mm

± 0.03%

MLBC-M16

1500 kgf

S-beam

17-4 PH Stainless Steel

93 °C

-40 °C

350 ± 10 Ω

300% FS

71 °C

17 °C

± 0.01%

150% FS

10 Vdc, 15 Vdc maximum

10 Vdc

0.0018% FSO/°C

1.6 kg

25 mm

20 AWG

Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input

± 1%

LCM101-250가격 문의

OMEGA Engineering

15 ft

5 POINT NIST

Cable

3 mV/V

MREC-M12M

Compression, Tension

0.02 in

51 mm

± 0.05%

350 ± 10 Ω

0.0025

76 mm

± 0.03%

MLBC-M12

250 kgf

S-beam

17-4 PH Stainless Steel

93 °C

-40 °C

350 ± 10 Ω

300% FS

71 °C

17 °C

± 0.01%

150% FS

10 Vdc, 15 Vdc maximum

10 Vdc

0.0018% FSO/°C

1.1 kg

25 mm

20 AWG

Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input

± 1%

LCM101-5001,078,070 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

15 ft

5 POINT NIST

Cable

3 mV/V

MREC-M12M

Compression, Tension

0.02 in

51 mm

± 0.05%

350 ± 10 Ω

0.0025

76 mm

± 0.03%

MLBC-M12

500 kgf

S-beam

17-4 PH Stainless Steel

93 °C

-40 °C

350 ± 10 Ω

300% FS

71 °C

17 °C

± 0.01%

150% FS

10 Vdc, 15 Vdc maximum

10 Vdc

0.0018% FSO/°C

1.1 kg

25 mm

20 AWG

Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input

± 1%

LCM101-10K2,354,500 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

15 ft

5 POINT NIST

Cable

3 mV/V

MREC-M24M

Compression, Tension

0.02 in

76 mm

± 0.05%

350 ± 10 Ω

0.0025

108 mm

± 0.03%

MLBC-M24

10000 kgf

S-beam

17-4 PH Stainless Steel

93 °C

-40 °C

350 ± 10 Ω

300% FS

71 °C

17 °C

± 0.01%

150% FS

10 Vdc, 15 Vdc maximum

10 Vdc

0.0018% FSO/°C

2 kg

38 mm

20 AWG

Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input

± 1%

LCM101-1001,091,270 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

30 ft

5 POINT NIST

Cable

3 mV/V

MREC-M6M

Compression, Tension

0.02 in

38 mm

± 0.05%

350 ± 10 Ω

0.0025

64 mm

± 0.03%

MLBC-M6

100 kgf

S-beam

17-4 PH Stainless Steel

93 °C

-40 °C

350 ± 10 Ω

300% FS

71 °C

17 °C

± 0.01%

150% FS

10 Vdc, 15 Vdc maximum

10 Vdc

0.0018% FSO/°C

0.45 kg

13 mm

24 AWG

Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input

± 1%

LCM101-5K가격 문의

OMEGA Engineering

15 ft

5 POINT NIST

Cable

3 mV/V

MREC-M24M

Compression, Tension

0.02 in

76 mm

± 0.05%

350 ± 10 Ω

0.0025

108 mm

± 0.03%

MLBC-M24

5000 kgf

S-beam

17-4 PH Stainless Steel

93 °C

-40 °C

350 ± 10 Ω

300% FS

71 °C

17 °C

± 0.01%

150% FS

10 Vdc, 15 Vdc maximum

10 Vdc

0.0018% FSO/°C

2 kg

38 mm

20 AWG

Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input

± 1%

LCM101-501,078,070 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

30 ft

5 POINT NIST

Cable

3 mV/V

MREC-M6M

Compression, Tension

0.02 in

38 mm

± 0.05%

350 ± 10 Ω

0.0025

64 mm

± 0.03%

MLBC-M6

50 kgf

S-beam

17-4 PH Stainless Steel

93 °C

-40 °C

350 ± 10 Ω

300% FS

71 °C

17 °C

± 0.01%

150% FS

10 Vdc, 15 Vdc maximum

10 Vdc

0.0018% FSO/°C

0.45 kg

13 mm

24 AWG

Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input

± 1%

LCM101-251,117,870 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

30 ft

5 POINT NIST

Cable

3 mV/V

MREC-M6M

Compression, Tension

0.02 in

38 mm

± 0.05%

350 ± 10 Ω

0.0025

64 mm

± 0.03%

MLBC-M6

25 kgf

S-beam

17-4 PH Stainless Steel

93 °C

-40 °C

350 ± 10 Ω

300% FS

71 °C

17 °C

± 0.01%

150% FS

10 Vdc, 15 Vdc maximum

10 Vdc

0.0018% FSO/°C

0.45 kg

13 mm

24 AWG

Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input

± 1%

LCM101-101,157,690 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

30 ft

5 POINT NIST

Cable

3 mV/V

MREC-M6M

Compression, Tension

0.02 in

38 mm

± 0.05%

350 ± 10 Ω

0.0025

64 mm

± 0.03%

MLBC-M6

10 kgf

S-beam

17-4 PH Stainless Steel

93 °C

-40 °C

350 ± 10 Ω

300% FS

71 °C

17 °C

± 0.01%

150% FS

10 Vdc, 15 Vdc maximum

10 Vdc

0.0018% FSO/°C

0.45 kg

13 mm

24 AWG

Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input

± 1%

LCM101-1K가격 문의

OMEGA Engineering

15 ft

5 POINT NIST

Cable

3 mV/V

MREC-M12M

Compression, Tension

0.02 in

51 mm

± 0.05%

350 ± 10 Ω

0.0025

76 mm

± 0.03%

MLBC-M12

1000 kgf

S-beam

17-4 PH Stainless Steel

93 °C

-40 °C

350 ± 10 Ω

300% FS

71 °C

17 °C

± 0.01%

150% FS

10 Vdc, 15 Vdc maximum

10 Vdc

0.0018% FSO/°C

1.1 kg

25 mm

20 AWG

Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input

± 1%
