FP7000 | Britestone

모델 보기

필터 또는 검색 기능을 사용하여 원하시는 모델을 찾으십시오.

총 1개의 상품

제품 번호 / 가격	Brand	Accuracy	Cable Length	Electrical Output	K-Factor	Material Construction Option	Materials, Wetted	Measurement Pressure Type	Operating Pressure Note	Operating Pressure, Max	Operating Pressure, Min	Operating Temperature, Max	Operating Temperature, Min	Output Detail	Pipe Size, Max	Pipe Size, Min	Pressure Drop Note	Pressure Drop, Max	Process Connection Size	Process Temperature, Max	Process Temperature, Min	Repeatability Error	Supply Current	Supply Power Note	Supply Voltage	Temperature Accuracy	Viscosity Range	Volumetric Flow Rate, Max	Volumetric Flow Rate, Min	수량 / 장바구니
FP7001A701,900 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	± 2 %	8 ft	Square Wave Pulse	1 Hz/fps	N/A	316 Stainless Steel, FKM, Polypropylene, PVC	Gauge	0 to 26°C (32 to 80°F) up to 150 psig; max. pressure decreases 1.1 psig per each 0.56°C (1°F) above 27°C (80°F) for a maximum temperature of 93°C (200°F) at 18 psig maximum	150 psi	0 psi	150 °C	2 °C	pulse	3 in	0.75 in	max pressure decreases 1.1 psig per each 0.56°C (1°F) above 27°C (80°F) for a max temperature of 93°C (200°F) at 18 psig maximum	1.1 psi	N/A	93 °C	0 °C	±1%	10 mA max	5 to 18 Vdc @ 10 mA maximum	5 to 18 Vdc	± 1 °C	5 cPs	460 GPM	2 GPM

스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.

제품 번호 / 가격

Brand

Accuracy

Cable Length

Electrical Output

K-Factor

Material Construction Option

Materials, Wetted

Measurement Pressure Type

Operating Pressure Note

Operating Pressure, Max

Operating Pressure, Min

Operating Temperature, Max

Operating Temperature, Min

Output Detail

Pipe Size, Max

Pipe Size, Min

Pressure Drop Note

Pressure Drop, Max

Process Connection Size

Process Temperature, Max

Process Temperature, Min

Repeatability Error

Supply Current

Supply Power Note

Supply Voltage

Temperature Accuracy

Viscosity Range

Volumetric Flow Rate, Max

Volumetric Flow Rate, Min

수량 / 장바구니

FP7001A701,900 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

± 2 %

8 ft

Square Wave Pulse

1 Hz/fps

N/A

316 Stainless Steel, FKM, Polypropylene, PVC

Gauge

0 to 26°C (32 to 80°F) up to 150 psig; max. pressure decreases 1.1 psig per each 0.56°C (1°F) above 27°C (80°F) for a maximum temperature of 93°C (200°F) at 18 psig maximum

150 psi

0 psi

150 °C

2 °C

pulse

3 in

0.75 in

max pressure decreases 1.1 psig per each 0.56°C (1°F) above 27°C (80°F) for a max temperature of 93°C (200°F) at 18 psig maximum

1.1 psi

N/A

93 °C

0 °C

±1%

10 mA max

5 to 18 Vdc @ 10 mA maximum

5 to 18 Vdc

± 1 °C

5 cPs

460 GPM

2 GPM
