총 1개의 상품

제품 번호 / 가격	Brand	Approvals	Configuration	Digital Input	Digital Output	Enclosure Ratings	Input Control Signal	Input Note	Length	Measurement Type	Number of Channels	Number of I/O	Operating Temperature, Max	Operating Temperature, Min	Software	Supply Power Type	Supply Voltage	Width	수량 / 장바구니
SP-014-1가격 문의101 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	CE, UKCA	Configurable via Omega Link Smart Interface and SYNC configuration software	VinHighThreshold = 2.2 VMAX, VinLowThreshold = 0.3 VMIN, VinMAX = 30 VDC	2x Open Drain 100 mA max, VMAX = 30 VDC	IP67	Current Loop: 4 to 20 mA, Voltage: 0 to 1.0 Vdc, 0 to 2.0 Vdc	ON: 1.0 Vdc, OFF: 0.7 Vdc, Internal Pull Up/Down: 1.5k to 3.0 Vdc, Comparator (Pulse) Input: 100 mV, 500 mV, 1.0 Vdc, 2.0 Vdc	96.7 mm	Process Current and Voltage	3	2	85 °C	-40 °C	Compatible with OEG, SYNC, and OMEGA Cloud	DC	2.8 to 3.3 Vdc	22.1 mm

스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.

제품 번호 / 가격

Brand

Approvals

Configuration

Digital Input

Digital Output

Enclosure Ratings

Input Control Signal

Input Note

Length

Measurement Type

Number of Channels

Number of I/O

Operating Temperature, Max

Operating Temperature, Min

Software

Supply Power Type

Supply Voltage

Width

수량 / 장바구니

SP-014-1가격 문의101 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

CE, UKCA

Configurable via Omega Link Smart Interface and SYNC configuration software

VinHighThreshold = 2.2 VMAX, VinLowThreshold = 0.3 VMIN, VinMAX = 30 VDC

2x Open Drain 100 mA max, VMAX = 30 VDC

IP67

Current Loop: 4 to 20 mA, Voltage: 0 to 1.0 Vdc, 0 to 2.0 Vdc

ON: 1.0 Vdc, OFF: 0.7 Vdc, Internal Pull Up/Down: 1.5k to 3.0 Vdc, Comparator (Pulse) Input: 100 mV, 500 mV, 1.0 Vdc, 2.0 Vdc

96.7 mm

Process Current and Voltage

85 °C

-40 °C

Compatible with OEG, SYNC, and OMEGA Cloud

2.8 to 3.3 Vdc

22.1 mm
