RTD 및 열전쌍 신호 컨디셔너, 절연형, DIN 레일 호환
필터 또는 검색 기능을 사용하여 원하시는 모델을 찾으십시오.
총 15개의 상품
| 제품 번호 / 가격 | Brand | Drift | Height | Input Control Signal | Input Type | Isolation | Isolator Input Current Range | Isolator Input Voltage Range | Isolator Output Current Range | Length | Linearity | Mounting | Output Load | Supply Power Note | Supply Power Type | Supply Voltage | Temperature Measurement Range | Thermocouple Type | Width | 수량 / 장바구니 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SCL4151C가격 문의9 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | RTD Search current < 500 µA | RTD | 1500 Vac RMS | 0 to 5 mA, 0 to 10 mA, 0 to 20 mA, 0 to 50 mA, 0 to 100 mA, 1 to 5 mA, 4 to 20 mA, 10 to 15 mA | 0 to 100 mV, 0 to 200 mV, 0 to 500 mV; 0 to 1 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, 2 to 10 V | - | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SCL: 12 to 24 VDC/VAC 50 to 400 Hz | AC/DC | 12 to 24 Vac/Vdc | 0 to 200°F | N/A | 0.866 in | |
SCL4151B가격 문의9 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | RTD Search current < 500 µA | RTD | 1500 Vac RMS | 0 to 5 mA, 0 to 10 mA, 0 to 20 mA, 0 to 50 mA, 0 to 100 mA, 1 to 5 mA, 4 to 20 mA, 10 to 15 mA | 0 to 100 mV, 0 to 200 mV, 0 to 500 mV; 0 to 1 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, 2 to 10 V | - | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SCL: 12 to 24 VDC/VAC 50 to 400 Hz | AC/DC | 12 to 24 Vac/Vdc | 0 to 100 °C | N/A | 0.866 in | |
SCL4130P가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | 3 M Ω impedance | RTD | 1500 Vac RMS | 0 to 5 mA, 0 to 10 mA, 0 to 20 mA, 0 to 50 mA, 0 to 100 mA, 1 to 5 mA, 4 to 20 mA, 10 to 15 mA | 0 to 100 mV, 0 to 200 mV, 0 to 500 mV; 0 to 1 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, 2 to 10 V | - | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SCL: 12 to 24 VDC/VAC 50 to 400 Hz | AC/DC | 12 to 24 Vac/Vdc | 0 to 2000°F | K | 0.866 in | |
SCL4130K가격 문의9 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | 3 M Ω impedance | RTD | 1500 Vac RMS | 0 to 5 mA, 0 to 10 mA, 0 to 20 mA, 0 to 50 mA, 0 to 100 mA, 1 to 5 mA, 4 to 20 mA, 10 to 15 mA | 0 to 100 mV, 0 to 200 mV, 0 to 500 mV; 0 to 1 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, 2 to 10 V | - | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SCL: 12 to 24 VDC/VAC 50 to 400 Hz | AC/DC | 12 to 24 Vac/Vdc | 0 to 500°F | K | 0.866 in | |
SCL4130D가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | 3 M Ω impedance | RTD | 1500 Vac RMS | 0 to 5 mA, 0 to 10 mA, 0 to 20 mA, 0 to 50 mA, 0 to 100 mA, 1 to 5 mA, 4 to 20 mA, 10 to 15 mA | 0 to 100 mV, 0 to 200 mV, 0 to 500 mV; 0 to 1 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, 2 to 10 V | - | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SCL: 12 to 24 VDC/VAC 50 to 400 Hz | AC/DC | 12 to 24 Vac/Vdc | 0 to 500°F | J | 0.866 in | |
SCL4130G가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | 3 M Ω impedance | RTD | 1500 Vac RMS | 0 to 5 mA, 0 to 10 mA, 0 to 20 mA, 0 to 50 mA, 0 to 100 mA, 1 to 5 mA, 4 to 20 mA, 10 to 15 mA | 0 to 100 mV, 0 to 200 mV, 0 to 500 mV; 0 to 1 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, 2 to 10 V | - | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SCL: 12 to 24 VDC/VAC 50 to 400 Hz | AC/DC | 12 to 24 Vac/Vdc | 0 to 1000°F | J | 0.866 in | |
SCL4380가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | 3 M Ω impedance | Isolator | 1500 Vac RMS | 0 to 5 mA, 0 to 10 mA, 0 to 20 mA, 0 to 50 mA, 0 to 100 mA, 1 to 5 mA, 4 to 20 mA, 10 to 15 mA | 0 to 100 mV, 0 to 200 mV, 0 to 500 mV; 0 to 1 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, 2 to 10 V | 0 to 1 mA, 0 to 5 mA, 0 to 20 mA, 1 to 5 mA, 4 to 20 mA | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SCL: 12 to 24 VDC/VAC 50 to 400 Hz | AC/DC | 12 to 24 Vac/Vdc | N/A | N/A | 0.866 in | |
SC4151B가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | RTD Search current < 500 µA | RTD | 1500 Vac RMS | - | - | - | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SC: 85 to 265 VDC/VAC 50 to 400 Hz | AC/DC | 85 to 265 Vac/Vdc | 0 to 100 °C | N/A | 0.866 in | |
SC4151D가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | RTD Search current < 500 µA | RTD | 1500 Vac RMS | - | - | - | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SC: 85 to 265 VDC/VAC 50 to 400 Hz | AC/DC | 85 to 265 Vac/Vdc | 0 to 200°F | N/A | 0.866 in | |
SC4130P가격 문의9 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | 3 M Ω impedance | Thermocouple | 1500 Vac RMS | - | - | - | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SC: 85 to 265 VDC/VAC 50 to 400 Hz | AC/DC | 85 to 265 Vac/Vdc | 0 to 2000°F | K | 0.866 in | |
SC4130K가격 문의11 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | 3 M Ω impedance | Thermocouple | 1500 Vac RMS | - | - | - | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SC: 85 to 265 VDC/VAC 50 to 400 Hz | AC/DC | 85 to 265 Vac/Vdc | 0 to 500°F | K | 0.866 in | |
SC4130G가격 문의9 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | 3 M Ω impedance | Thermocouple | 1500 Vac RMS | - | - | - | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SC: 85 to 265 VDC/VAC 50 to 400 Hz | AC/DC | 85 to 265 Vac/Vdc | 0 to 1000°F | J | 0.866 in | |
SC4130D가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | 3 M Ω impedance | Thermocouple | 1500 Vac RMS | - | - | - | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SC: 85 to 265 VDC/VAC 50 to 400 Hz | AC/DC | 85 to 265 Vac/Vdc | 0 to 500°F | J | 0.866 in | |
SC4380가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | Current: 600 Ω max ; voltage: 500 Ω min (20 mA maximum) | RTD | 1500 Vac RMS | 0 to 5 mA, 0 to 10 mA, 0 to 20 mA, 0 to 50 mA, 0 to 100 mA, 1 to 5 mA, 4 to 20 mA, 10 to 15 mA | 0 to 100 mV, 0 to 200 mV, 0 to 500 mV; 0 to 1 V, 0 to 5 V, 0 to 10 V, 1 to 5 V, 2 to 10 V | 0 to 1 mA, 0 to 5 mA, 0 to 20 mA, 1 to 5 mA, 4 to 20 mA | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SC: 85 to 265 VDC/VAC 50 to 400 Hz | AC/DC | 85 to 265 Vac/Vdc | N/A | N/A | 0.866 in | |
SC4130A가격 문의9 weeks리드타임은 상황에 따라 달라질 수 있습니다. | Dwyer a DwyerOmega Brand | ± 0.02%/°C (typical), ± 0.05%/°C (max) | 2.95 in | 3 M Ω impedance | Thermocouple | 1500 Vac RMS | - | - | - | 3.88 in | 0.1% of full-scale | DIN Rail - 35 mm (DIN EN50022-35) | Current: 600 Ω max ; Voltage: 500 Ω min (20 mA maximum) | SC: 85 to 265 VDC/VAC 50 to 400 Hz | AC/DC | 85 to 265 Vac/Vdc | -100 to 200°C | J | 0.866 in |
