PTC-20 | Britestone

모델 보기

필터 또는 검색 기능을 사용하여 원하시는 모델을 찾으십시오.

총 2개의 상품

제품 번호 / 가격	Brand	Accuracy	Activation Time	Contact Rating	Control Mode	Cutout Dimensions	Display Note	Display Type	Enclosure Ratings	Form factor	Frequency	Height	Humidity Range	Impedance	Inhibit	Inputs Start and Reset	Length	Measurement Type	Memory	Number of Relays	Number of Timer Functions	Operating Temperature, Max	Operating Temperature, Min	Power Consumption	Resolution	Storage Temperature, Max	Storage Temperature, Min	Supply Power Type	Supply Voltage	Timer Range	Weight	Width	수량 / 장바구니
PTC-23797,120 원9 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	± 0.01 %	21 ms	Relay: 2 SPDT (5 A), 15 ms max latency,Transistor:NPN Open Collector: 30 Vdc, 30 mA max opto isolated	Repeat Cycle: Batch stop, batch continue and interval	45 x 45 mm	Dual-line, 4-digit, 7-segment LED, 8 mm H (0.31")	Dual 4 Digit LED	IP65	1/16 DIN	50/60 Hz	48 mm	5 to 95% RH, non-condensing	10 kΩ	NPN or Dry Contact	NPN or dry contact	85 mm	Time	Non-volatile	2	17	55 °C	0 °C	10 VA	Settable for time values in hours/minutes/seconds ranges	90 °C	-40 °C	AC	90 to 240 Vac	Hours, minutes, seconds; hours, minutes; minutes, seconds	100 g	48 mm
PTC-22800,560 원9 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	± 0.01 %	21 ms	Relay: 2 SPDT (5 A), 15 ms latency,Transistor: NPN,Open Collector: 30 Vdc, 30 mA max	Repeat Cycle: Batch stop, batch continue and interval	45 x 45 mm	Dual-line, 4-digit, 7-segment LED, 8 mm H (0.31")	Dual 4 Digit LED	IP65	1/16 DIN	50/60 Hz	48 mm	5 to 95% RH, non-condensing	10 kΩ	NPN or Dry Contact	NPN or dry contact	85 mm	Time	Non-volatile	2	3	55 °C	0 °C	10 VA	Settable for time values in hours/minutes/seconds ranges	90 °C	-40 °C	AC	90 to 240 Vac	Hours, minutes, seconds; hours, minutes; minutes, seconds	100 g	48 mm

스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.

제품 번호 / 가격

Brand

Accuracy

Activation Time

Contact Rating

Control Mode

Cutout Dimensions

Display Note

Display Type

Enclosure Ratings

Form factor

Frequency

Height

Humidity Range

Impedance

Inhibit

Inputs Start and Reset

Length

Measurement Type

Memory

Number of Relays

Number of Timer Functions

Operating Temperature, Max

Operating Temperature, Min

Power Consumption

Resolution

Storage Temperature, Max

Storage Temperature, Min

Supply Power Type

Supply Voltage

Timer Range

Weight

Width

수량 / 장바구니

PTC-23797,120 원9 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

± 0.01 %

21 ms

Relay: 2 SPDT (5 A), 15 ms max latency,Transistor:NPN Open Collector: 30 Vdc, 30 mA max opto isolated

Repeat Cycle: Batch stop, batch continue and interval

45 x 45 mm

Dual-line, 4-digit, 7-segment LED, 8 mm H (0.31")

Dual 4 Digit LED

IP65

1/16 DIN

50/60 Hz

48 mm

5 to 95% RH, non-condensing

10 kΩ

NPN or Dry Contact

NPN or dry contact

85 mm

Time

Non-volatile

55 °C

0 °C

10 VA

Settable for time values in hours/minutes/seconds ranges

90 °C

-40 °C

90 to 240 Vac

Hours, minutes, seconds; hours, minutes; minutes, seconds

100 g

48 mm

PTC-22800,560 원9 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

± 0.01 %

21 ms

Relay: 2 SPDT (5 A), 15 ms latency,Transistor: NPN,Open Collector: 30 Vdc, 30 mA max

Repeat Cycle: Batch stop, batch continue and interval

45 x 45 mm

Dual-line, 4-digit, 7-segment LED, 8 mm H (0.31")

Dual 4 Digit LED

IP65

1/16 DIN

50/60 Hz

48 mm

5 to 95% RH, non-condensing

10 kΩ

NPN or Dry Contact

NPN or dry contact

85 mm

Time

Non-volatile

55 °C

0 °C

10 VA

Settable for time values in hours/minutes/seconds ranges

90 °C

-40 °C

90 to 240 Vac

Hours, minutes, seconds; hours, minutes; minutes, seconds

100 g

48 mm
