디지털 히트 트레이스 컨트롤러 및 디지털 온도 조절기
필터 또는 검색 기능을 사용하여 원하시는 모델을 찾으십시오.
총 3개의 상품
| 제품 번호 / 가격 | Brand | Additional Features 1 | Alarm | Alarm Note | Applications | Approvals | Contact Type | Control Mode | Control Output | Current Rating | Deadband | Deadband Type | Display Type | Enclosure Ratings | Frequency | Height | Input Type | Input Type Note | Length | Number of Circuits | Operating Temperature, Max | Operating Temperature, Min | Process Temperature, Max | Process Temperature, Min | Setpoint | Supply Voltage | Width | Data Interface | Keypad | LED Indicators | 수량 / 장바구니 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
ITC2가격 문의38 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | Class 1 Div 2, UL/cUL, CE | Low & High Temperature, Low & High Current, High GFEP, Sensor Failure; Functionality: Closed, Open, Open | - | - | UL/cUL Ordinary and Class I, Division 2, Groups A,B,C,D Hazardous Locations. (UL File: E347725) CE | N/A | Manual, On/Off, Auto (PID) | SSR Relay | 40 A | 2 to 100˚F | - | TFT LCD | IP66, NEMA Type 4X | 50/60 Hz | 262 mm | RTD (Pt100) | Sensor Type- 3-wire RTD, 100 W PT, 0.00385 W/W/˚C, 20 W balanced lead wire Number of Sensor Inputs- 1 or 2 per Circuit Sensing Configuration- Range: Single, Low, High, Average, Use RTD1 to control both circuits | 197 mm | 2 | 40 °C | -40 °C | 593 °C | -62 °C | - | 100 to 277 Vac | 213 mm | Modbus RTU, RS485 | 5 capacitive Touch Input Buttons | Power (Green), Load (Amber), Alarm (Red) – Per Ckt | |
ITC1가격 문의38 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | Class 1 Div 2, UL/cUL, CE | Low & High Temperature, Low & High Current, High GFEP, Sensor Failure; Functionality: Closed, Open, Open | - | - | UL/cUL Ordinary and Class I, Division 2, Groups A,B,C,D Hazardous Locations. (UL File: E347725) CE | N/A | Manual, On/Off, Auto (PID) | SSR Relay | 40 A | 2 to 100˚F | - | TFT LCD | IP66, NEMA Type 4X | 50/60 Hz | 262 mm | RTD (Pt100) | Sensor Type- 3-wire RTD, 100 W PT, 0.00385 W/W/˚C, 20 W balanced lead wire Number of Sensor Inputs- 1 or 2 per Circuit Sensing Configuration- Range: Single, Low, High, Average, Use RTD1 to control both circuits | 197 mm | 1 | 40 °C | -40 °C | 593 °C | -62 °C | - | 100 to 277 Vac | 213 mm | Modbus RTU, RS485 | 5 capacitive Touch Input Buttons | Power (Green), Load (Amber), Alarm (Red) – Per Ckt | |
DTS가격 문의7 weeks리드타임은 상황에 따라 달라질 수 있습니다. | OMEGA Engineering | Soft Start: User selectable integral soft start, patent pending software algorithm, which eliminates nuisance breaker tripping associated with self-regulating cable in-rush | High temp to 1150°F (621°C);Low temp to -80°F (-62°C);RTD Failure;Red LED alarm status indicator on front panel; Functionality: Closed, Open, Open | Solid State Alarm Rating - AC 12-277 VAC, 1.8 Amps RMS - Customer Supplied Solid State Alarm Rating - DC 0-42 VDC, 1.8 Amps RMS- Customer Supplied | Freeze Protection, Temperature Maintenance | Current Aprrovals • CE, UL, cUL Listed • Ordinary Areas • Hazardous Area • Class I, Div. 2 – Groups A, B, C, D • ATEX/IECEx Zone II (Ex nA IIC) | N/A | On/Off | SSR Relay | 30 A | 1 to 100˚F | Programmable | LED | NEMA Type 4X | 50/60 Hz | 289 mm | RTD (Pt100) | 100 Ohm Platinum RTD | 121 mm | N/A | 60 °C | -40 °C | 593 °C | -62 °C | -80°F to 1100°F programmable (-62˚C to 593˚C) | 120 to 277 Vac | 160 mm | - | - | - |
