PS-RDN20-Srs-P-S--Module

모델 보기

필터 또는 검색 기능을 사용하여 원하시는 모델을 찾으십시오.

총 2개의 상품

제품 번호 / 가격	Brand	Approvals	Current Rating	Dropout Voltage	EMC Standard	Electrical Output	Height	Input Current	Isolation	Length	MTBF	Number of Inputs	Operating Humidity	Operating Temperature, Max	Operating Temperature, Min	Power Consumption	Relative Humidity	Relay Note	Relay Rating	Reverse Voltage	Storage Temperature, Max	Storage Temperature, Min	Vibration	Weight	Width	Withstand Voltage	수량 / 장바구니
DR-75-24V350,500 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	EN60950-1, LP-PS-4524 UL508 Harmonic Current: Compliance to EN61000-3-2,-3 Mounting: Compliance to IEC60068-2-8	3.125 A	0.5 V	EN 55022B, ENV 50204A, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8	24 Vdc	125.2 mm	20 A	Terminal-Chassis: >100M Ω/500 Vdc 25°C (77ºF) 70% RH	100 mm	1,000,000 hours	2	20 to 90% RH non-condensing	70 °C	-20 °C	N/A	10 to 95%	Input Voltage Alarm: When input is 30V (±5%), relay contacts close	30 Vdc, 1A	30V	85 °C	-40 °C	10 to 500 Hz, 2G 10 min/ 1 cycle, period for 60 min each along X, Y, Z axes	0.5 kg	55.5 mm	Terminal-Chassis: 0.5 K Vac, Relay Contacts-Terminal: 0.5 K Vac
PS-RDN20210,330 원9 weeks리드타임은 상황에 따라 달라질 수 있습니다.	OMEGA Engineering	EN60950-1, LP-PS-4524 UL508 Harmonic Current: Compliance to EN61000-3-2,-3 Mounting: Compliance to IEC60068-2-9	0.041666666666667	0.5 V	EN 55022B, ENV 50204A, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8	20 Vdc	125.2 mm	20 A	Terminal-Chassis: >100M Ω/500 Vdc 25°C (77ºF) 70% RH	100 mm	1,000,000 hours	2	20 to 90% RH non-condensing	70 °C	-20 °C	N/A	10 to 95%	Input Voltage Alarm: When input is 30V (±5%), relay contacts close	30 Vdc, 1A	30V	85 °C	-40 °C	10 to 500 Hz, 2G 10 min/ 1 cycle, period for 60 min each along X, Y, Z axes	0.5 kg	55.5 mm	Terminal-Chassis: 0.5 K Vac, Relay Contacts-Terminal: 0.5 K Vac

스페이스를 누른 채 마우스 휠을 움직이면 표를 좌우로 스크롤할 수 있습니다.

제품 번호 / 가격

Brand

Approvals

Current Rating

Dropout Voltage

EMC Standard

Electrical Output

Height

Input Current

Isolation

Length

MTBF

Number of Inputs

Operating Humidity

Operating Temperature, Max

Operating Temperature, Min

Power Consumption

Relative Humidity

Relay Note

Relay Rating

Reverse Voltage

Storage Temperature, Max

Storage Temperature, Min

Vibration

Weight

Width

Withstand Voltage

수량 / 장바구니

DR-75-24V350,500 원2 weeks리드타임은 상황에 따라 달라질 수 있습니다.

OMEGA Engineering

EN60950-1, LP-PS-4524 UL508 Harmonic Current: Compliance to EN61000-3-2,-3 Mounting: Compliance to IEC60068-2-8

3.125 A

0.5 V

EN 55022B, ENV 50204A, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8

24 Vdc

125.2 mm

20 A

Terminal-Chassis: >100M Ω/500 Vdc 25°C (77ºF) 70% RH

100 mm

1,000,000 hours

20 to 90% RH non-condensing

70 °C

-20 °C

N/A

10 to 95%

Input Voltage Alarm: When input is 30V (±5%), relay contacts close

30 Vdc, 1A

30V

85 °C

-40 °C

10 to 500 Hz, 2G 10 min/ 1 cycle, period for 60 min each along X, Y, Z axes

0.5 kg

55.5 mm

Terminal-Chassis: 0.5 K Vac, Relay Contacts-Terminal: 0.5 K Vac

PS-RDN20210,330 원9 weeks리드타임은 상황에 따라 달라질 수 있습니다.
