DwyerOmegaVolatile-Organic-Compounds
VOC-R
VOC, ROOM MOUNT, 0-1000 PPB,4-20 MA AND
- 판매 가격
- 가격 문의
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 6 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Applications:Air and HVAC, Building and Maintenance, Environmental Monitoring
CO2 Measurement Range:0_to_1000_ppb
Data Interface:Modbus RTU, RS485
Electrical Connection:Screw Terminal
Electrical Output:4 to 20 mA, 0 to 10 Vdc
Enclosure Material:ABS Plastic
Gas Concentration:0 to 1000 ppm
Load Resistance:4-20 mA: 500 Ohms maximum (Default)
Material Construction Option:none
Measuring Range:0-1000 ppb
Operating Humidity:10 to 95% RH, non-condensing
Operating Temperature, Max:122 °F
Operating Temperature, Min:32 °F
Response Time:<5 seconds
Sensor Type:Metal Oxide Semiconductor
Series ID:Volatile-Organic-Compounds
Storage Temperature, Max:140 °F
Storage Temperature, Min:-4 °F
Supply Current:50 mA
Supply Voltage:16 to 28 Vac, 16 to 35 Vdc
Tightening Torque:0.45 lb-in (0.5 Nm) nominal
Trip Point Note:230 ppb
Warm Up Time:15 minutes
Wire Gauge:22 to 16 AWG
