DwyerOmegaPSW-850
PSW-852BK
0 to 50 psi, fixed deadband
- 가격
- 1,520,770 원
- VAT 10%
- 152,077 원
- 총 금액
- 1,672,847 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 7 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Approvals:UL, CE compliant
Control Output:SPDT Relay
Deadband Type:Fixed
Electrical Connection:Screw Terminal
Enclosure Ratings:NEMA Type 1
Height:4 in
Length:5.5 in
Materials:316 Stainless Steel, Aluminum, Epoxy, Stainless Steel
Materials, Wetted:316 Stainless Steel
Measurement Pressure Type:Gauge
Measurement Pressure, Max:50 psi
Measurement Pressure, Min:0 psi
Operating Temperature Note:-40 to 70°C (-40 to 160°F), except model PSW-852A: -40 to 70°C (0 to 160°F); set point typically shifts less than 1% of range for a 30°C (54°F) ambient temperature change
Operating Temperature, Max:70 °C
Operating Temperature, Min:-40 °C
Process Connection Size:1/4 in
Process Connection Type:NPT Female
Proof Pressure:Up to 225 psi
Sensor Type:Diaphragm
Setpoint Repeatability:± 2%
Setpoint Repeatability Note:± 2% of adjustable range, except model PSW-852E: ± 3% of adjustable range
Shock:Setpoint repeats after 15 g, 10 ms duration
Storage Temperature, Max:71 °C
Storage Temperature, Min:-54 °C
Switch:Dual
Switch Note:2 or 3 SPDT; switches can be separated up to 100%, except models PSW-852A and PSW-852B: 30%; switches can be wired “normally open” or “normally closed”.
Switch Type:SPDT NO/NC, Selectable
Vibration:Setpoint repeats after 2.5 g, 5 to 500 Hz
Weight:7.5 lb
Weight Note:Approx. 1.4 to 3.4 kg (3 to 7.5 lb) (varies with model)
Width:4.9 in
