DwyerOmegaPSW-190
PSW-197
110 to 1,500 psi, fixed deadband
- 가격
- 379,940 원
- VAT 10%
- 37,994 원
- 총 금액
- 417,934 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 10 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Additional Features 1:FKM O-Ring
Approvals:UL listed
Control Output:SPDT Relay
Deadband:23 to 253 psi
Deadband Type:Fixed
Diameter:1.26 in
Height:4.37 in
Materials:Aluminum, Brass
Materials, Wetted:Brass, Buna-N (NBR), Stainless Steel
Measurement Pressure Type:Gauge
Measurement Pressure, Max:1500 psi
Measurement Pressure, Min:110 psi
Operating Temperature, Max:80 °C
Operating Temperature, Min:-20 °C
Output Note:SPDT, 5 A at 250 Vac or 30 Vdc gold-clad silver contacts for loads down to 5 mA at 6 Vdc, 2 mA at 12 Vdc and 1 mA at 24 Vdc
Output Value:5A @ 250 Vac
Process Connection Size:1/4 in
Process Connection Type:NPT Male
Process Temperature, Max:120 °C
Process Temperature, Min:0 °C
Proof Pressure:Up to 10000 psi
Repeatability:± 1.5%
Sensor Type:Diaphragm
Shock:Setpoint repeats after 50 g, 10 ms duration
Switch:Single
Switch Type:SPDT NO/NC, Selectable
System Pressure, Max:8000 psi
Vibration:Setpoint repeats after 10 g, 5 to 500 cps
Weight:4.5 oz
Weight Note:128 g (4.5 oz)
Wiring/Connector Table:Black - N/C, Blue - N/O, Common - Violet
