DwyerOmegaPM1000-Series
PM1001
Plug-on Local Display
- 가격
- 511,130 원
- VAT 10%
- 51,113 원
- 총 금액
- 562,243 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 11 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Accuracy:± 0.25 %
Accuracy Detail:±0.25% full scale includes linearity, and hysteresis
Additional Features 1:Plug-on display
Burst Pressure:2
Case Material:Stainless Steel
Control Output:Open drain
Electrical Connection:DIN 43650 A (solenoid valve)
Electrical Output:4 to 20 mA
Enclosure Ratings:IP65
Humidity Range:0.95
Long Term Stability:±0.2%
Materials, Wetted:Titanium
Operating Temperature, Max:80 °C
Operating Temperature, Min:-40 °C
Output Detail:4 to 20 mA (2-Wire) with zero and span adjustments
Process Connection Size:1/4 in
Process Connection Type:NPT Male
Process Temperature, Min:-50 °C
Repeatability:±0.1%
Response Time:10 ms
Sensor Type:Silicon on Sapphire
Supply Power Note:13 to 36 Vdc with PM1000 18 to 36 Vdc reverse polarity protected; Load Driving Capacity: 1150Ω @ 36 Vdc, R maximum = (Vs-13)/20 with PM1000 R maximum = (Vs-18)/20
Supply Voltage:13 to 36 Vdc
Thermal Span Effect:<±0.016% FS/°F
Thermal Zero Effect:<±0.016% FS/°F
Weight:90 g
