DwyerOmegaOME-ET-PET-7000--Series
OME-PET-7017-10
Ethernet Remote I/O Modules
- 가격
- 1,394,660 원
- VAT 10%
- 139,466 원
- 총 금액
- 1,534,126 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 6 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Accuracy:± 0.1 %
Analog I/O Note:Analog Input Note: Channels: 10 differential or 20 single ended*, software selectable;Type: ±150 mV, ±500 mV, ±1V, ±5V, ±10V, ±20 mA,0 to 20 mA, 4 to 20 mA (Jumper Selectable);Individual Channel Configuration: Yes;Resolution;Normal Mode: 16-bit;Fast Mode: 12-bit;Sampling Rate;Normal Mode: 10 samples/second (total) ;Fast Mode: 60 samples/second (total) ;Accuracy;Normal Mode: ±0.1%;Fast Mode: ±0.5% or better;Zero Drift: ±20 μV/°C;Span Drift: ±25 ppm/°C;Overvoltage Protection;Differential: 240 Vrms ;Single Ended: 150 Vrms ;Input Impedance;Voltage: 2 MΩ (differential), 1 MΩ(single-ended);Current: 125 Ω;Common Mode Rejection: 86 dB minimum;Normal Mode Rejection: 100 dB
Bandwidth:500 Hz
CMRR:86 dB
Channel Current:5.0A/channel at 25°C
Current Measurement Range:±20 mA, 0 to 20 mA, 4 to 20 mA
Data Interface:Ethernet
Data Interface Note:Modbus TCP, Modbus UDP;Ethernet Port: 10/100 base-TX with Auto MDI/ MDI-Xwith PoE (Power over Ethernet);Watchdog: Dual: Yes, module (0.8 seconds), communication (programmable);Security: ID, Password and IP filter;Web HMI: Yes, I/O Pair Connection: Yes
Digital I/O Note:Digital Input: None, Digital Output :None
Digital Input:N/A
Drift:Zero: ±20 μV/°C, Span: ±25 ppm/°C
Electrical Output:N/A
Height:35 mm
Impedance Input:Voltage 2 MΩ (differential), 1 MΩ (single-ended), Current 125 Ω
Input Type:Voltage, Current
Isolation:Input to Output Isolation: 2500 Vdc
LED Indicators:L1 (System Running): Yes, L2 (Ethernet Link/Act): Yes, L3 (Ethernet 10/100 M Speed): Yes, PoE: Yes
Length:123 mm
Mounting:DIN-Rail or Wall Mount
NMRR:100 dB
Number of Channels, Input:Analog: 10 DIFF/20 SE
Number of Channels, Output:None
Operating Temperature, Max:75 °C
Operating Temperature, Min:-25 °C
Output Signal:None
Power Consumption:3.8 W
Relative Humidity:10 to 90% RH, non-condensing
Sampling Rate:10 Hz to 60 Hz (10 to 60 updates/second)
Storage Temperature, Max:80 °C
Storage Temperature, Min:-30 °C
Supply Power Note:Power Requirements: Reverse Polarity Protection: Yes Powered from PoE: Yes, IEEE 802.3af, class1
Supply Voltage:12 to 48 Vdc
Voltage Measurement Range:±150 mV, ±500 mV, ±1V, ±5V, ±10V
Width:72 mm
