DwyerOmegaOM-CP-XTCTemp-Series
OM-CP-X16TCTEMP-A2
X-Series - 16 Channel Thermocouple Logger
- 가격
- 3,556,290 원
- VAT 10%
- 355,629 원
- 총 금액
- 3,911,919 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 2 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Additional Features 1:NIST Traceable Calibration
Battery Size and Type:Li-ion, 10V
Battery life:up to 18 mo
Calibration:Digital calibration through software
Data Interface:WiFi
Data Interface Note:USB-A to micro USB cable (included); 460,800 baud
Electrical Connection:Screw Terminal
Enclosure:Aluminium
Form factor:Benchtop
Height:54.4 mm
LED Indicators:1 per channel and 2 status LEDs
Length:65.6 mm
Measurement Type:Temperature
Memory:131008
Number of Inputs:16
Number of Measurements:16
Operating Humidity:0 to 95% RH
Operating Temperature, Max:60 °C
Operating Temperature, Min:-20 °C
Process Temperature, Max:60 °C
Process Temperature, Min:-20 °C
Real Time Recording:May be used with PC to monitor and record data in real time
Samples,Max:2000000
Sampling Rate:1 day
Sampling Rate Note:4 Hz up to 1 reading every 24 hours
Software Compatibility:Windows® XP/VISTA/7 and 8 (32- and 64-bit)
Start Modes:Adjustable Delay Start, Immediate Start
Supply Power Type:Battery
Temperature Accuracy:± 0.5 °C
Temperature Resolution:0.01 °C
Temperature Sensor Type:Thermocouple
Thermocouple Resistance, Max:1000 Ω
Time Accuracy:± 1 minute/month
Weight:800 g
Width:184.2 mm
Wire Gauge:24 AWG
