DwyerOmegaOM-CP-PRHTEMP101A-Logger
OM-CP-PRHTEMP101A
- 가격
- 588,110 원
- VAT 10%
- 58,811 원
- 총 금액
- 646,921 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 2 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Alarm Note:Programmable high and low limits; alarm is activated when recording environment reaches or exceeds set limits (pressure channel only).
Battery Size and Type:3.6V Li-ion
Battery life:up to 10 yr
Calibration:Digital calibration through software
Data Interface:USB
Data Interface Note:USB (interface cable required); 115,200 baud
Form factor:Handheld
LED Indicators:Green LED Blinks: 10 second rate to indicate logging 15 second rate to indicate delay start mode; Red LED Blinks: 10 second rate to indicate low battery and/or full memory 1 second rate to indicate an alarm condition
Length:36 mm
Measurement Pressure, Max:1300 mBar
Measurement Pressure, Min:250 mBar
Measurement Type:Humidity, Pressure, Temperature
Memory:412876
Memory Note:Manual or Trigger Mode, Memory Reading Per Channel 688128
Number of Measurements:3
Operating Temperature, Max:80 °C
Operating Temperature, Min:-40 °C
Pressure Calibrated Accuracy:10 mbar
Pressure Resolution:0.02 mbar
Pressure Sensor Type:Piezo resistive
Real Time Recording:The device may be used with a PC to monitor and record data in real time.
Relative Humidity Accuracy:± 3% RH
Relative Humidity Accuracy Note:± 3% RH (± 2% RH typical @ 25°C)
Relative Humidity Resolution:0.001
Relative Humidity Sensor Type:Capacitive Polymer
Relative Humidity, Max:0.95
Relative Humidity, Min:0%
Samples,Max:670000
Sampling Rate:0.5 Hz (2 seconds between updates)
Sampling Rate Note:1 reading every 2 seconds to 1 every 12 hours
Software Compatibility:Windows XP SP3/Vista/7 and 8 (32-bit and 64-bit)
Start Modes:Adjustable Delay Start, Immediate Start, Push-button
Stop Modes:Adjustable Delay Stop, Manual Through Software
Supply Power Type:Battery
Temperature Accuracy:± 0.5 °C
Temperature Measurement, Max:80 °C
Temperature Measurement, Min:-40 °C
Temperature Resolution:0.01 °C
Temperature Sensor Type:RTD
Temperature Sensor Type Note:Precision RTD Element
Time Accuracy:± 1 minute/month @ 25 °C
Weight:24 g
Width:56 mm
