DwyerOmegaOM-CP-XVoltage-Series
OM-CP-OCTVOLT-3.2V-A2
X-Series - 8 Channel Voltage Logger ±3.2V Range
- 가격
- 2,317,400 원
- VAT 10%
- 231,740 원
- 총 금액
- 2,549,140 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 4 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Accuracy Detail:Nominal range @ 25°C
Additional Features 1:NIST Traceable Calibration
Approvals:CE, ROHS
Baud Rate:460800
Calibration Accuracy:±0.0032 V
Calibration Note:Digital calibration through software, automatically recorded within device
Conversion Time:150 milliseconds
Current Measurement Range:N/A
Data Interface:USB
Electrical Connection:Removable Screw Terminal
Frequency Rejection:50 to 60 Hz
Height:7.25 in
Impedance Input:125 kΩ
Input Control Signal:±3.2 V
Input Voltage:+ 50 V
LED Functionality:1 Per Channel and 2 Status LEDs
Length:1.22 in
Materials:Aluminum
Measurement Type:Voltage
Memory:349,354 readings
Memory Note:349,354 readings per channel
Number of Channels:8
Operating Temperature, Max:60 °C
Operating Temperature, Min:-20 °C
Real Time Recording:May be used with PC to monitor and record data in real time
Relative Humidity:0 to 95% RH
Resolution:0.0004 mV
Sampling Rate Note:4 Hz to 1 reading every 24 hours
Software:Windows XP SP3/7/8/10, Standard Software version 4.2.19.0 or later, Secure Software version 4.2.18.0 or later
Start Modes:Button Push, Delayed Start, Immediate Start
Supply Power:9 V Lithium Battery
Supply Power Note:18 Months Typical
Supply Power Type:Battery
Temperature Coefficient:25 ppm/°C
Time Accuracy:±1 minute/month
Voltage Measurement Range:± 3.2 V
Weight:368 g
Width:2.7 in
