Brand:OMEGA Engineering
AC Adaptor Operating Temperature:0 to 40 °C
Alarm:Two contact inputs, TTL 0.5 mA with 10K pull-up; one open collector output 150 mA @ 30 Vdc
Approvals:CE, FCC-B
Battery Operating Temperature:-18 to 55 °C
Battery Size and Type:Alkaline 9V
Cable Temperature, Max:125 °C
Cable Temperature, Min:-40 °C
Certifications:NIST Traceable Calibration
Configuration:Internal Web UI
Data Interface:Ethernet
Data Interface Note:Ethernet : (RJ45) Fixed or auto negotiating 10/100BASE-T, AUTO MDI/MDIX Protocols: TCP, UDP, SNMP, SMTP, NTP, ARP, ICMP, DHCP, DNS, HTTP, and Telnet
Display:LCD
Display Note:32 digits 4.8 x 9.7 mm (0.19 x 0.38")
Form factor:Wall Bracket Mount
Height:1.31 in
Input Type:External
Length:3.47 in
Measurement Type:Thermocouple
Memory:2 GB SD Flash Card
Memory Note:2GB card: 8 months of data storage at 1 second recording intervals or 7 years at 10 second intervals
Number of Measurements:2
Number of Relays:2
Operating Temperature, Max:60 °C
Operating Temperature, Min:0 °C
Pressure Resolution:0.1 mbar
Relay Output:1.5 A @ 30 Vdc
Samples,Max:85k Samples, Interval 16 Samples / Second, 1 Second recording intervals or 7 years at 10 sec intervals
Sensor Type:Thermocouple
Software:OPC Server; macro for data logging in Excel program; compatible with Windows® operating systems
Storage Temperature, Max:85 °C
Storage Temperature, Min:-40 °C
Supply Power Note:Safety Qualified AC Power Adaptor:, Input: 100 to 240 Vac, 50/60 Hz, Nominal Output: 9 Vdc @ 0.5 A,(included), Back-up Battery: 9 Vdc, alkaline (included)
Supply Power Type:DC/Battery
Supply Voltage:9 to 12 Vdc
Temperature Measurement, Max:1372 °C
Temperature Measurement, Min:260 °C
Temperature Resolution:0.1 °C
Temperature Stability:0.08°C/°C
Thermocouple Cold End Tracking:0.05°C/°C
Thermocouple Lead Resistance:100 Ω max
Thermocouple Type:K
Weight:1.02 lb
Width:5.13 in
