DwyerOmegaSeries-IS626
IS626-08-GH-P1-E1-S1
IS626-08-GH-P1-E1-S1 XMTR
- 판매 가격
- 가격 문의
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 8 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:Dwyer a DwyerOmega Brand
Accuracy:± 0.25 %
Accuracy Detail:0.25% FS
Applications:Chemical Refineries, Fluid Measurement and Control, Industrial and Manufacturing
Burst Pressure:150 psi Maximum
Compensated Temperature, Max:176 °F
Compensated Temperature, Min:0 °F
Compliance:CE, cULus, IS UL-913
Electrical Connection:Cable
Electrical Output:4 to 20 mA
Enclosure Ratings:IP66, NEMA Type 4X
Loop Resistance:0 to 900 Ω max
Materials, Wetted:316 Stainless Steel, 316L Stainless Steel
Measurement Pressure Type:Gauge
Measurement Pressure, Max:30 psi
Measurement Pressure, Min:0 psi
Media Compatibility:Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
Mounting Orientation:Not Position Sensitive
Operating Temperature, Max:176 °F
Operating Temperature, Min:0 °F
Output Detail:4 to 20 mA
Output Signal:Current
Power Consumption:38 mA
Process Connection Size:1/4 in
Process Connection Type:NPT Male
Proof Pressure:Up to 30 psi
Response Time:50 ms
Supply Power Type:DC
Supply Voltage:10 to 28 Vdc
Thermal Effects:± 0.02% FS/°F (includes zero and span)
Weight:252 g
