DwyerOmegaFMG70B-Series
FMG71B-A
Electromagnetic Low Flow Meter
- 가격
- 3,567,620 원
- VAT 10%
- 356,762 원
- 총 금액
- 3,924,382 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 19 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Accuracy:± 1.5 %
Accuracy Detail:± 1.5% of reading ± 0.3% range
Conductivity:50 µS/cm
Current, Max:26_ma_approx
Electrical Connection:M12 4 pin Female
Enclosure Ratings:IP65, NEMA Type 4X
Flange Diameter:0.39 in
Flow Indication:LED Green
Flow Indication Note:flow proportional blinking
Load Resistance:250 Ω
Materials:PEEK, Aluminum
Materials, Wetted:EPDM, Stainless Steel
Media Compatibility:Acid Solutions, Conductive Liquids, Saltwater
Number of Outputs:1
Operating Pressure, Max:232 psi
Operating Temperature, Max:70 °C
Operating Temperature, Min:5 °C
Output Detail:Amplified Square Wave
Output Pulse Rate Note:Square wave signal NPN, internal pull-up resistor 2 kΩ pulse duty ratio 50:50
Output Signal:Current
Power Consumption:150 mA
Process Connection Size:1/2 in
Process Connection Type:NPT Male
Process Temperature, Max:90 °C
Process Temperature, Min:0 °C
Repeatability:± 1%
Response Time:< 500 ms
Sensor Diameter:0.25 in
Short-Circuit Protected:< 30 V
Short-Circuit Protected Note:Measures short-circuit proof (up to 30V) and polarity protection (up to -30V)
Supply Power Note:24 Vdc ± 10%
Supply Power Type:DC
Supply Voltage:24 Vdc
Volumetric Flow Rate, Max:7.93 GPM
Volumetric Flow Rate, Min:0.13 GPM
