DwyerOmegaF72C-Series
F74H-4AD-AD0
Excelon® Oil Removing (Coalescing) Filters for Compressed Air Systems with Partical Removing Element
- 판매 가격
- 가격 문의
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: Limited Stock리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Body Material:Aluminum
Control Mode:Automatic
Element Material Note:Synthetic fiber and polyurethane foam
Filter:Oil removing filter
Flow Characteristic:High Flow
Housing Material Note:Transparent with Guard: Polycarbonate, steel guard ;Indicator Lens: Transparent nylon ,Element: Synthetic fiber and polyurethane foam ,Elastomers: Neoprene and nitrile; Materials Body: Transparent nylon ,Internal parts: Acetal ,Spring: Stainless steel ,Elastomers: Nitrile
Operating Temperature Note:Metal Bowl: -34 to 65 °C; Transparent Bowl: -34 to 50 °C
Operating Temperature, Max:65 °C
Operating Temperature, Min:-34 °C
Particle Size, Max:0.01 μm
Pressure Note:Pressure for Manual Drain Transparent Bowl, Max: 150 psig; Pressure for Automatic Drain Transparent Bowl, Max: 116 psi; Pressure for Manual Drain Metal Bowl, Max: 250 psi; Pressure for Automatic Drain Metal Bowl, Max: 116 psi
Process Connection Size:1/2 in
Process Connection Type:NPT
Target Gas:Compressed Air
Volumetric Flow Rate, Max:59.3 SCFM
Weight:1.11 kg
Window:Polycarbonate
