DwyerOmegaDRC-8900-Series-Sig-Cond
DRC-8906
- 판매 가격
- 가격 문의
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 41 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Accuracy:± 0.1 %
Additional Features 1:Slim Housing Mounts on DIN Rail
CMRR:85 dB
Current Measurement Range:4 to 20 mA
Height:110 mm
Impedance Input:Voltage: 1 MΩ minimum, Current: 50 Ω typical
Input Range Note:Maximum Input: Voltage input models, 130 VRMS; current input models, 65 mA (3.25 volts across 50 Ω input resistance)
Input Type:Current
Isolation:700 V
Length:77 mm
Linearity:±0.02%
Load Resistance:0 to 500 Ω
Materials:Plastic
Mounting:DIN Rail Mount
Number of Inputs:1
Open_Circuit Voltage:13 V
Operating Temperature, Max:55 °C
Operating Temperature, Min:0 °C
Output Signal:Voltage
Output Value:Process
Response Time:10 ms (10 to 90%)
Storage Temperature, Max:80 °C
Storage Temperature, Min:-40 °C
Supply Power Note:22 to 26 Vdc (unregulated); 15 mA (models DRC-8920/21/40/41/42), 20 mA
Supply Power Type:DC
Supply Voltage:22 to 26 Vdc
Temperature Coefficient:Zero, ±0.5 mV/°C (0 to 10 V output models), ±0.5 microamp/°C (4 to 20 mA output models); full scale, ±100 ppm/°C typical
Voltage Output Range:0 to 10 V
Weight:142 g
Width:22.5 mm
