DwyerOmegaDIN-100-Series-Sig-Cond
DIN-115
Din Rail Mount Digital Transmitters
- 가격
- 453,830 원
- VAT 10%
- 45,383 원
- 총 금액
- 499,213 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 2 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Accuracy:± 0.05 %
Additional Features 1:Address: User Selectable Channel address; Multi-Drop Modules: Up to 247 multi-drop modules per host serial port
Approvals:CE
Baud Rate:300 to 38,400
CMRR:100 dB at 50/60Hz, 500V RMS max CMV, input to output at 60Hz
Calibration:Autozero and autocalibration; no adjustment pots
Conversion Rate:8 Conversions per Second
Data Format:NRZ Asynchronous
Data Interface:Modbus RTU, ASCII, RS485
Electrical Connection:Screw Terminal
Excitation Voltage:10 Vdc
Filter:Digital Filtering: Small and large signal with user selectable time ;constants from 0 to 16 seconds
Height:83.9 mm
Input Range Note:+10 mV, +100 mV, +1V, +5V, +10V, +100 Vdc
Input Type:Voltage
Leakage Current:< 2 μA
Length:86.5 mm
Materials:ABS
Memory:Non Volatile Memory Eliminates pots and Switches
Microcomputer:8-bit CMOS; digital scaling, linearization and calibration
Number of Inputs:1
Offset:Offset Control: Full input range
Operating Temperature, Max:70 °C
Operating Temperature, Min:-25 °C
Output Signal:RS485
Output Value:Process
Parity:Odd, Even, None
Protection:Input Burnout: 250 Vac
Relative Humidity:0 to 95% RH (non-condensing)
Resolution:0.01% (4 digits)
Serial Number:Input Burnout Protection: To 250 Vac normal mode
Software:Windows PC Software
Storage Temperature, Max:85 °C
Storage Temperature, Min:-25 °C
Supply Power Note:Regulated +5 Vdc, 0.75 W max (DIN-150, 2.0 W max); protected against power supply reversals
Supply Power Type:DC
Supply Voltage:± 5 Vdc
Temperature Coefficient:Span Temperature Coefficient: +50 ppm/°C max
Voltage Measurement Range:100 V
Width:25.4 mm
Zero Drift:+1 Count max (autozero)
