DwyerOmegaD8000-Series
D8200
USB Interface Modules
- 가격
- 729,740 원
- VAT 10%
- 72,974 원
- 총 금액
- 802,714 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 2 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Analog I/O Note:Analog Input Note: Current: Number of Channels: 7 differential current inputs, Range: ±20 mA, Resolution ADC: 16-bit ADC, 25/20 conversions per second, Accuracy: ±0.05% of FS maximum, Span Tempco: ±50ppm/°C maximum, Voltage Drop: 2.0V maximum, Input impedance: <100 Ω (70 typical), Power Requirements: Serial = 1.4W
Common Mode Voltage:Input to Output at 115 Vrms, 60 Hz: 500 Vrms
Conversion Rate:25/20 conversions/sec
Current Measurement Range:± 20 mA
Data Interface:USB
Data Interface Note:Modbus RTU protocol;Configuration Method: Modbus
Digital Filter:Programmable
Electrical Connection:Screw Terminal
Electrical Output:0 to 20 mA, 4 to 20 mA
Height:102 mm
Impedance Input:<100 Ω (70 typical)
Input Type:Current
Input Voltage Note:Absolute Maximum Input Voltage: ±10V
Isolation:500 Vac, Input common to System ground
Length:38 mm
Materials:ABS
Memory:EEPROM
Mounting Note:165 mm on center
Number of Channels, Input:Analog: 7 DIFF
Number of Channels, Output:None
Operating Temperature, Max:70 °C
Operating Temperature, Min:-25 °C
Output Settling Time:0.1% FS: 1 ms
Output Signal:None
Pull-up Resistor:10 kΩ
Relative Humidity:0 to 95% RH non-condensing
Storage Temperature, Max:85 °C
Storage Temperature, Min:-25 °C
Supply Power Note:Power Requirements: Serial = 1.4 W
Supply Power Type:DC
Supply Voltage:10 to 30 Vdc
Temperature Coefficient:±50 ppm/°C
Width:152 mm
