DwyerOmegaD6000-Series
D6720
Modbus® Serial Interface Modules
- 가격
- 609,260 원
- VAT 10%
- 60,926 원
- 총 금액
- 670,186 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 2 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:OMEGA Engineering
Baud Rate:9600 to 115200
Common Mode Voltage:Input to Output at 115 Vrms, 60 Hz: 500 Vrms
Conversion Rate:4.5 Hz
Data Interface:RS485
Data Interface Note:Modbus RTU protocol;Configuration Method: Modbus
Digital Filter:Programmable
Digital I/O Note:Number of Channels: 15 Open-collector outputs to 30 Vdc, 100 mA maximum, Vsat: +0.3 Vdc maximum at 100 mA, Short Circuit Protection: To 500 mA, Communications: Watchdog timer, Digital Output Update Rate: 4.5 Hz, Isolation: 500 Vac, output common to system ground, Power Requirements: Serial = 1.0W
Digital Output:5 mA minimum, 10 mA maximum
Electrical Connection:Screw Terminal
Height:102 mm
Input Type:N/A
Isolation:500 Vac, Output common to System ground
Length:38 mm
Materials:ABS
Memory:EEPROM
Mounting Note:165 mm on center
Number of Channels, Output:Digital: 15
Operating Temperature, Max:70 °C
Operating Temperature, Min:-25 °C
Output Settling Time:0.1% FS: 1 ms
Output Signal:Digital
Pull-up Resistor:10 kΩ
Relative Humidity:0 to 95% RH non-condensing
Storage Temperature, Max:85 °C
Storage Temperature, Min:-25 °C
Supply Power Note:Power Requirements: Serial = 1.0 W
Supply Power Type:DC
Supply Voltage:10 to 30 Vdc
Transmission Distance:1219 m
Width:152 mm
