DwyerOmegaSeries-A1F
A1F-O-SS-1-2
Pressure switch, range 4-75 psig (0.28-5.17 bar), min. deadband 4 psig (0.27 bar), max. deadband 15 psig (1.0 bar).
- 판매 가격
- 가격 문의
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 4 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:Dwyer a DwyerOmega Brand
Applications:Industrial and Manufacturing, Pump Control
Compliance:cULus
Deadband:2 to 3 psi
Electrical Connection:Screw Terminal
Materials, Wetted:316 Stainless Steel, Fluorocarbon
Measurement Pressure Type:Gauge
Measurement Pressure, Max:75 psi
Measurement Pressure, Min:4 psi
Media Compatibility:Consult Factory
Mounting Orientation:20° Off Vertical
Operating Temperature, Max:175 °F
Operating Temperature, Min:-40 °F
Pressure Limits:Up to 500 psi
Process Connection Size:1/2 in x 1/4 in
Process Connection Type:NPT Male and Female
Set Point Adjustment:External Cap
Switch Note:15 A @ 120/240/480 VAC; 1/8 HP @ 125 VAC; 1/4 HP @ 250 VAC.
Switch Rating:15 A @ 120/240/480 Vac; 1/8 HP @ 125 Vac; 1/4 HP @ 250 Vac
Switch Type:SPDT Snap
Weight:10.5 oz
