DwyerOmega4-20mA-Output-Current-Sensor

A/CTA2-250-RMS

Analog Current Sensor, 4-20mA, DIN Rail, Solid Core, RMS, 0-100, 0-200, 0-250 Amp (Default)

가격: 533,750 원

VAT 10%: 53,375 원

총 금액: 587,125 원

수량

재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.

무료 배송 10만원 이상

납기: 4 weeks리드타임은 상황에 따라 달라질 수 있습니다.

연구비카드 사용가능

실시간 문의하기

제품 사양

Accuracy:± 1 %

Accuracy Detail:All Models: +/- 1 % of Selected Range except A/SCTA2-50-RMS: +/- 2 % from 15 Hz to 20 Hz, +/- 1 % from 20 Hz to 100 Hz

Applications:Air and HVAC, Building and Maintenance, Electronic Equipment, Environmental Monitoring, Flow Measurement, Industrial and Manufacturing, R&D/Engineering Testing

Cable Type:Insulated Shielded

Calibration Note:All current output sensors are calibrated at an ambient room temperature of 21.5 °C (71 °F)

Electrical Connection:Screw Terminal

Electrical Output:4 to 20 mA

Enclosure Material:ABS, Polycarbonate

Enclosure Ratings:UL94 V-0

Isolation:2200 Vac

Materials:ABS

Measurement Type:Current

Operating Temperature, Max:104 °F

Operating Temperature, Min:5 °F

Relative Humidity:0 to 95%, Non-Condensing

Series ID:4-20mA-Output-Current-Sensor

Storage Temperature, Max:95 °F

Storage Temperature, Min:41 °F

Supply Current:25 mA, min

Supply Power Note:+8.5 Vdc to 30 Vdc (ReversePolarity Protected); 250 Ohm Load (1 Vdc to 5 Vdc): +13.5 Vdc to 30 Vdc; 500 Ohm Load (2 Vdc to 10Vdc): +18.5 Vdc to 30 Vdc

Supply Voltage:8.5 to 30 Vdc

Tightening Torque:0.5 Nm to 0.6 Nm (4.43 in-lb to 5.31 in-lb)

Wire Gauge:24 to 18 AWG

문서 및 매뉴얼

4-20mA-Output-Current-Sensor Data Sheet

PDF

i0000789.pdf - i0000789_pdf_aci_pdf
