DwyerOmegaFixed-Status-Switches
A/CS2
Fixed Current Switch, DIN Rail, Solid Core, NO,
- 가격
- 152,740 원
- VAT 10%
- 15,274 원
- 총 금액
- 168,014 원
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 6 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Applications:Air and HVAC, Building and Maintenance, Control Panel, Environmental Monitoring, Flow Measurement, Heating Equipment, Industrial and Manufacturing
Electrical Connection:Screw Terminal
Enclosure Material:ABS, Polycarbonate
Enclosure Ratings:UL94 V-0
Frequency:40 to 1 kHz
Isolation:2200 Vac
LED Indicators:Red
Materials:ABS
Measurement Type:AC Current
Operating Temperature, Max:104 °F
Operating Temperature, Min:5 °F
Relative Humidity:0 to 95%, Non-Condensing
Response Time:See Chart
Series ID:Fixed-Status-Switches
Setpoint Type:Fixed
Supply Power Type:Induction
Supply Voltage:Induced from the Monitored Conductor
Switch Rating:0.2 A @ 200 Vac/Vdc
Tightening Torque:4.43 to 5.31 in-lbs. (0.5 to 0.6 Nm)
Wire Gauge:22 to 16 AWG
