DwyerOmegaSeries-605
605-20
range 0-20" w.c., max. pressure 11 psi (75.8 kPa), ± 0.5% electrical accuracy, ± 2% mechanical accuracy.
- 판매 가격
- 가격 문의
수량
재고: 0개국내 재고가 없어도 주문 가능합니다. 주문 시 해외 재고를 확인합니다.
무료 배송 10만원 이상
납기: 8 weeks리드타임은 상황에 따라 달라질 수 있습니다.
연구비카드 사용가능
실시간 문의하기제품 사양
Brand:Dwyer a DwyerOmega Brand
Accuracy:Electrical: ± 0.5 %, Mechanical: ± 2 %
Accuracy Detail:Electrical: ± 4%, Mechanical: ± 4% (includes linearity, hysteresis, repeatability)
Compensated Temperature, Max:48.9 °C
Compensated Temperature, Min:0 °C
Compliance:CE
Dial Depth:68 mm
Dial Dia:4 in
Dial Outer Diameter:127 mm
Display Type:N/A
Electrical Connection:Screw Terminal
Electrical Output:4 to 20 mA
Long Term Stability:± 1% FS/year
Loop Resistance:0 to 1250 Ω max
Material Construction Option:Standard
Materials, Wetted:Consult Factory
Measurement Pressure Type:Differential
Measurement Pressure, Max:20 inH₂O
Measurement Pressure, Min:0 inH₂O
Media Compatibility:Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases
Mounting Note:Vertical Diaphragm
Operating Temperature, Max:48.9 °C
Operating Temperature, Min:-6.67 °C
Output Signal:Current
Power Consumption:max 38 mA
Process Connection Size:1/8 in
Process Connection Type:NPT Female
Proof Pressure:Up to 10 psi
Span Adjustment:Potentiometers
Supply Power Type:DC
Supply Voltage:10 to 35 Vdc
Thermal Effects:± 0.045% FS/°C
Weight:811 g
Zero Setting Adjustable Range:Protected Potentiometers
